HIMax MODULAR SAFETY SYSTEM
X-BASE PLATE
The X-BASE PLATE forms the mechanical and electrical foundation of the HIMax programmable electronic system. It accommodates HIMax modules and connector boards while integrating redundant power distribution and the system-bus structure required for modular controller configurations.
|
SYSTEM RACK / BASE STRUCTURE
HIMax
Modular Safety Controller Platform
Base plate variants support different module counts and mounting arrangements.
◆ Redundant system-bus concept
X-BP
|
|
01 / POSITION
System
Foundation |
The HIMA X-BASE PLATE is part of the HIMax programmable electronic system and is designed as the mounting platform for HIMax modules. The base-plate family includes versions with 10, 15 or 18 slots, allowing the rack structure to be selected according to the required controller configuration. The first two positions are reserved for the system-bus modules. The remaining positions accommodate the applicable HIMax modules through corresponding connector boards. The architecture is intended for systems where availability, modularity and controlled replacement of hardware are important. |
|
02 / CORE DATA
Technical
Profile Engineered around a modular rack architecture with redundant supply paths and dedicated system-bus connections.
|
|
|
03 / RACK ARCHITECTURE
Built Around the Module
System-bus concept: the two left positions are reserved for the system-bus modules. Redundant system buses A and B support continued operation within a base plate if one system bus fails.
Connector-board based module mountingModular expansion architecture
|
MOUNTING OPTIONS
X-BASE PLATE 10 01
10-slot version for mounting plate / backplane arrangement. X-BASE PLATE 15 01
15-slot version for mounting plate / backplane arrangement. X-BASE PLATE 15 02
15-slot version designed for 19-inch frame mounting. X-BASE PLATE 18 01
18-slot version for mounting plate / backplane arrangement. |
|
04 / ELECTRICAL FOUNDATION
Redundant
Power Path The base plate uses redundant 24 VDC supply connections through L1 and L2 supply paths. The architecture permits the modules to be supplied from either rail or from both rails in parallel. |
|
| 05 / INSTALLATION PROFILE Physical & Connection Data | |||||||||||||||||
|
|
||||||||||||||||
|
DIMENSION MAP
Rack Sizes
Dimensions vary according to the selected slot capacity and mounting configuration. |
|
|
06 / APPLICATION CONTEXT
When the Rack
Becomes Critical In a HIMax installation, the base plate is not simply a mechanical holder. It provides the physical framework for modules, connector boards, redundant supply paths and system-bus connections. |
Typical replacement situation
A replacement search for an X-BASE PLATE is especially relevant when a rack has mechanical damage, connector-board mounting problems, power-distribution abnormalities, or when an existing base plate must be restored to the correct slot configuration. Why it matters: because the base plate carries the system's module mounting and communication infrastructure, an incorrect or incompatible rack configuration can prevent the controller from being restored as planned and can extend the duration of a plant shutdown.
Important matching point: identify the exact X-BASE PLATE variant, slot capacity and mounting arrangement before replacing an installed rack.
|
| 07 / FAMILY STRUCTURE X-BASE PLATE Family | ||||
|
|
|
AMIKON INDUSTRIAL AUTOMATION
20 Years of
Industrial Excellence Since 2005, Amikon has developed a broad industrial automation spare-parts network serving maintenance, modernization and emergency replacement requirements across international markets. 551,867 spare parts supplied ◆ 128 manufacturers ◆ Adequate inventory
|
  |
|
08 / BUYER QUESTIONS
X-BASE PLATE
FAQ |
Q1. How do I choose the correct HIMA X-BASE PLATE when replacing an installed rack?
Confirm the existing slot capacity and mounting arrangement first. The X-BASE PLATE family includes 10-slot, 15-slot and 18-slot versions, while X-BASE PLATE 15 02 is specifically intended for 19-inch frame mounting. Matching the installed mechanical arrangement is therefore essential. Q2. Can HIMA X-BASE PLATE be treated as only a mechanical rack?
No. The base plate also incorporates the redundant power-distribution structure and system-bus arrangement. Its connector-board architecture is part of the functional installation of HIMax modules. Q3. Why are the first two HIMA X-BASE PLATE positions treated differently?
Slots 1 and 2 are reserved for the system-bus modules and are equipped with connector boards for system bus A and system bus B. The remaining positions are assigned according to the rack configuration. Q4. What should I verify if a HIMA X-BASE PLATE replacement is associated with an unexpected system fault?
Check that the replacement rack matches the required variant, that the corresponding connector boards are correctly assigned, and that the redundant 24 VDC supply connections and polarity are correct. An incorrectly coded connector board can cause system malfunction. Q5. Does the HIMA X-BASE PLATE itself perform the safety function?
The base plate provides the physical and electrical infrastructure for the HIMax system; the safety functions are implemented by the appropriate HIMax modules and system configuration rather than by the rack alone. |
|
09 / ORDER SUPPORT
Ready for
Maintenance Needs For a faster quotation, please provide the exact part number and the installation details below. Quote checklist
Part Number · Quantity · Destination · Required Date · Machine/System |
|
|
Return & Replacement
If you have any question after receiving the item, please contact us within 7 days. Returned items should remain in their original condition and include the specific reason for return. After the returned item is received, we can arrange a return or replacement according to the case. Shipping costs arising from the return are the buyer's responsibility.
|
|
10 / RECOMMENDED INDUSTRIAL PARTS
Additional Models
A mixed selection of industrial automation components for maintenance and replacement planning.
|
||||||||||||||||||||||||||||||||||||||||||||||||
|
|
11 / DIRECT CONTACT
Need the Right
X-BASE PLATE? Send the exact part number, required quantity and machine/system details. Our sales team can help confirm the configuration before quotation. |
