INDUSTRIAL OPERATOR INTERFACE
IC755CKW07CDM
QuickPanel+ 7-inch Screen with RSTi Modbus TCP
The IC755CKW07CDM is a 7-inch QuickPanel+ operator interface designed to combine industrial visualization, operator interaction and RSTi Modbus TCP connectivity in one compact panel-mounted platform. Its widescreen TFT display, projected-capacitive two-point touch interface, Ethernet connectivity and serial interfaces make it suitable for machine-level and plant-floor operator interaction where clear process visibility and dependable communication are required. |
QUICKPANEL+ SERIES
07"
800 × 480 TFT LCD
|
|
PART NUMBER
IC755CKW07CDM
|
PLATFORM
QuickPanel+ 7-inch
|
COMMUNICATION
RSTi Modbus TCP
|
FORM FACTOR
Panel-mounted HMI
|
|
|
One Panel, Multiple Operator Functions
QuickPanel+ was designed as a multifunctional operator platform. It combines operator interface functions with process control capabilities, gateway functions and optional data historian capabilities, helping reduce the number of separate devices required at the machine or plant-floor level. The platform supports serial and Ethernet connectivity for interaction with controllers and I/O from multiple vendors. Its Windows Embedded Compact 7 environment also provides browser and multimedia capabilities for applications requiring local access to operational resources. |
WHY THIS CONFIGURATION
7-inch visualization + RSTi Modbus TCP
A practical configuration for installations that need a compact operator display while communicating with RSTi distributed I/O through Ethernet.
|
|
ENGINEERING DATA
IC755CKW07CDM Technical Profile
|
|||||||||||||||||||||||||||
|
|
||||||||||||||||||||||||||
|
|
||||||||||||||||||||||||||
|
|||||||||||||||||||||||||||
|
FIELD ROLE
Where IC755CKW07CDM Fits
IC755CKW07CDM is intended for QuickPanel+ installations where operators need a local visualization and control interface while the panel communicates with RSTi distributed I/O through Modbus TCP. The platform can also communicate with industrial controllers and I/O through Ethernet and serial interfaces. Typical machine-floor roles include monitoring process values, viewing alarms and operating status, entering operator commands, supervising connected equipment and presenting graphical process information at the point of operation. In a running installation, a failed panel can remove the operator's normal local view and command interface even when the underlying control equipment remains operational. Loss of Ethernet communication with distributed I/O can additionally leave process values unavailable or prevent expected operator interaction. For this reason, replacement selection should match the existing panel size, communication arrangement, power requirement and application configuration. |
COMMON REPLACEMENT TRIGGERS
01 Display or touch operation becomes unreliable
02 Ethernet communication with RSTi I/O is lost
03 Panel power failure interrupts local operation
04 An existing QuickPanel+ installation requires a direct configuration match
|
|
QUICKPANEL+ FAMILY
Related 7-inch & Multi-size Configurations
|
||||||||||||||||
|
|
SUPPLY ARRANGEMENT
Replacement Planning Made Simple
For a replacement request, matching the exact part number is important because QuickPanel+ configurations differ by screen size, communication function and other hardware options. |
|
||||||||
|
FAST QUOTATION
Send These Details
Providing the following details helps us check the requested configuration and arrange a faster quotation. |
|
||||||
|
AMIKON INDUSTRIAL AUTOMATION
Spare Parts Support for Automation Systems
|
Amikon focuses on industrial automation PLC modules, control-system components and replacement parts, with a business goal centered on helping customers maintain productivity and reduce avoidable downtime.
Our product coverage spans major automation families including HIMA, ABB, Rockwell Automation, ICS Triplex, Triconex, Woodward, GE, Yokogawa, Bently Nevada and Emerson automation platforms.
|
AUTOMATION COVERAGE
Multi-brand Industrial Parts
Our portfolio covers control, safety, motion, HMI, monitoring and process-automation equipment across a broad range of industrial systems. |
|
|
Can IC755CKW07CDM replace a failed 7-inch QuickPanel+ in an existing RSTi Modbus TCP installation?
It is the 7-inch QuickPanel+ configuration specifically identified for RSTi Modbus TCP. Before replacement, the existing application, Ethernet arrangement, power supply, panel cutout and RSTi network configuration should be checked so the replacement matches the installed system.
Does IC755CKW07CDM provide enough interfaces for a mixed Ethernet and serial machine?
The 7-inch configuration provides two 10/100BaseT Ethernet ports, one RS-232 port and one RS-485 port, together with USB interfaces and an SD/SDHC card slot. This makes it suitable where the replacement needs both network and serial connectivity.
What should be checked if IC755CKW07CDM shows the HMI but RSTi values are not updating?
Check the Ethernet connection first, then verify the configured RSTi Modbus TCP network arrangement and the application mapping used by the installation. A communication problem can leave the operator interface available while process values from distributed I/O are no longer updated.
|
Is IC755CKW07CDM suitable for a replacement where the enclosure reaches 50°C?
The specified operating temperature range is 0°C to +55°C, so a 50°C enclosure temperature is within the stated operating range. Natural convection is used for cooling, so the enclosure installation should still allow appropriate heat dissipation.
What makes IC755CKW07CDM different from the other 7-inch QuickPanel+ configurations?
The key distinction is its RSTi Modbus TCP configuration. Other 7-inch QuickPanel+ part numbers are assigned to RSTi-EP Modbus TCP or View and Control configurations. The exact suffix should therefore be matched before ordering rather than selecting a 7-inch model by screen size alone.
Replacement tip:
When the machine is stopped because the operator interface is unavailable, send the complete part number together with the machine/system details so the replacement can be checked against the intended configuration.
|
|
