PACSystems™ RX3i
IC695PNS101
Advanced PROFINET Scanner Module
The IC695PNS101 is an RX3i Advanced PROFINET Scanner designed to connect an RX3i I/O rack to a PROFINET I/O Controller. It scans the configured I/O modules in its rack and exchanges I/O data across the PROFINET network.
|
PROFINET I/O ARCHITECTURE
Industrial Ethernet • Remote I/O • Advanced SOE capability
|
|
01 / HARDWARE
Four Ports
Two shielded RJ-45 copper interfaces and two SFP cages provide multiple Ethernet media options.
|
02 / NETWORK
10/100/1000
Copper ports support 10/100/1000 Mbps Ethernet; fiber interfaces support 100/1000 Mbps.
|
03 / TOPOLOGY
MRP
Supports daisy-chain, line, star and ring configurations using PROFINET Media Redundancy Protocol.
|
04 / SOE
Advanced
The PNS101 is optimized for RX3i Sequence of Events applications and provides clock synchronization status handling.
|
|
WHERE IC695PNS101 FITS
Remote I/O communication when timing and network continuity matter
The IC695PNS101 is used in PACSystems RX3i architectures where a remote I/O rack must exchange process data with a PROFINET I/O Controller. Its Advanced Scanner design is particularly relevant to Sequence of Events applications, where accurate event timing can be important when investigating process disturbances or equipment trips.
When customers commonly start looking for an IC695PNS101
A failed or unstable scanner, loss of PROFINET I/O communication, incorrect rack configuration, or a remote I/O node that no longer exchanges data can make the scanner a critical replacement candidate. In a production system, loss of the scanner can interrupt the data path between the controller and the affected I/O rack, potentially forcing the associated process or machine into a fault or stopped state.
|
NETWORK CHARACTER
PROFINET V2.3 • Class A I/O Device • MRP-capable network topology
|
|
551,867
spare parts supplied
|
128
manufacturers
|
Global
spare-parts support
|
|
Can IC695PNS101 replace a general RX3i PROFINET scanner when SOE capability is required?
Yes. IC695PNS101 is the Advanced PROFINET Scanner variant and is specifically optimized for RX3i Sequence of Events applications. It retains the core scanner role of connecting the RX3i I/O rack to a PROFINET I/O Controller.
|
Will IC695PNS101 work with an existing RX3i rack containing mixed I/O modules?
It is designed to scan supported Series 90-30 and RX3i I/O modules in the remote rack. Compatibility should be checked against the installed module types and the scanner firmware level before replacement.
|
|
Why would IC695PNS101 be considered during a PROFINET remote I/O failure?
Because the scanner is the communication point between the PROFINET I/O Controller and the modules in its rack. If the scanner cannot operate or cannot maintain the expected network exchange, the associated remote I/O data path can be interrupted and the controlled process may enter a fault condition.
|
Does IC695PNS101 support redundant PROFINET network arrangements?
The scanner supports PROFINET Media Redundancy Protocol configurations and ring topology. The appropriate network design, controller configuration and device settings must match the installed architecture.
|
|
What should be checked before ordering an IC695PNS101 as an emergency replacement?
Confirm the exact catalog number and hardware revision, the installed RX3i backplane and I/O configuration, the PROFINET architecture, and the application requirements. For an SOE installation, confirm that the replacement configuration matches the timing and event-recording requirements of the existing system.
|
|
|
