CONTROL CORE
RX3i CPU
Designed for RX3i control, communications and modular backplane architectures.
|
|||||||||
|
|||||||||
|
RX3i CONTROL ARCHITECTURE
CPU → Backplane → I/O
IC695CPE302-BBAB operates as the central processing element of a PACSystems RX3i system. The CPU communicates with RX3i I/O and intelligent option modules across the RX3i backplane while Ethernet and serial interfaces provide connections to programming, HMI, SCADA and other supported control-system devices.
The architecture allows the CPU to coordinate local control logic while supported communication services connect the controller with supervisory and networked automation devices.
|
COMMUNICATION LAYER
Network Services
Ethernet Global Data
Controller-to-controller data exchange within supported RX3i architectures. Modbus TCP
Supported master and slave communication functions. OPC UA Server
Structured industrial data access for supported applications. HTTP / HTTPS
Web-based controller services supported on CPE302-Bxxx hardware. |
||||||||
|
BXXX HARDWARE PLATFORM
IC695CPE302-BBAB Revision Context
The IC695CPE302-BBAB belongs to the Bxxx hardware generation of the RX3i CPE302 family. The BBAB revision is associated with firmware version 10.85 and adds support for -JC or later IC695CHS007, IC695CHS012 and IC695CHS016 backplanes.
For replacement planning, match the installed CPU revision with the RX3i backplane generation, configured features and existing application environment.
|
MEMORY RETENTION
Energy Pack Architecture
The RX3i CPE302 platform uses an Energy Pack approach for retaining user memory during loss of system power. The Energy Pack condition is therefore an important point to check during replacement and commissioning work.
The real-time clock uses a separate battery arrangement from the Energy Pack memory-retention function.
|
||||||||
|
|||||||||
|
SYSTEM FIT
Where the CPE302-BBAB Sits
|
REPLACEMENT CHECK
Before Installation
◆ Confirm the complete catalog number.
◆ Check the installed RX3i backplane revision. ◆ Check Energy Pack condition. ◆ Review firmware and PAC Machine Edition requirements. ◆ Verify the required Ethernet services. |
||||||||
|
AMIKON SALES DESK
IC695CPE302-BBAB
For availability, replacement planning, quantity requests and application matching.
|
|
|
01 — Can IC695CPE302-BBAB be used as a replacement for another CPE302 CPU?
Replacement should be checked by the complete catalog number, hardware generation, installed RX3i backplane and application requirements. The Bxxx platform is a later hardware generation than the CPE302-Axxx platform, so a direct substitution should not be assumed solely from the shared CPE302 base number.
|
02 — What should be checked when IC695CPE302-BBAB is being installed into an existing RX3i rack?
Check the backplane revision, CPU firmware requirements, PAC Machine Edition compatibility, Energy Pack condition and the communication services required by the application. For the BBAB revision, compatibility with the supported -JC or later CHS007, CHS012 and CHS016 backplanes is particularly relevant.
|
|
03 — Does IC695CPE302-BBAB provide the same Ethernet architecture as earlier CPE302 versions?
The Bxxx hardware generation introduced a new front-panel layout and two Gigabit Ethernet ports. This differs from earlier CPE302-Axxx hardware, so network topology and connection requirements should be reviewed when migrating or replacing an earlier unit.
|
04 — Is IC695CPE302-BBAB suitable when the application depends on OPC UA?
The CPE302-Bxxx platform supports an OPC UA Server, and the Bxxx firmware history includes OPC UA enhancements. The exact feature set available to an application depends on the installed firmware and configuration, so the required OPC UA function should be checked against the target system before replacement.
|
|
05 — Why does the IC695CPE302-BBAB revision matter when replacing an RX3i CPU during maintenance?
The revision determines the applicable hardware platform and compatibility considerations. IC695CPE302-BBAB belongs to the Bxxx generation and is associated with firmware 10.85, including support for -JC or later CHS007, CHS012 and CHS016 backplanes. Matching the installed rack, firmware environment and required network functions helps avoid an unsuitable replacement.
|
|
