GE IC200BEM003 PROFIBUS-DP Master Module

GE IC200BEM003
GE IC200BEM003
GE IC200BEM003

GE IC200BEM003 PROFIBUS-DP Master Module

Calculate shipping
Quotation Request
VERSAMAX MODULAR I/O
IC200BEM003

PROFIBUS-DP Master module for VersaMax modular control and I/O architectures.
◇ PROFIBUS-DP MASTER
◇ MODULAR NETWORKING
DATA RATE
9.6 K–12 Mbaud
SLAVE DEVICES
Up to 125
CONNECTOR
9-pin D-sub
Designed to place PROFIBUS-DP master communication directly into a VersaMax modular control architecture.
We have a wide range of brands and products for various industries, we provide services to tens of thousands of customers around the world.
✉ Email: sales@amikon.cn ☎ WhatsApp: 86-18020776792
Sales manager: Miya zheng
●—●—●



VERSAMAX / NETWORK COMMUNICATION
IC200BEM003
PROFIBUS-DP Master Module
GE VersaMax communication architecture
Designed for PROFIBUS-DP master communication within VersaMax and supported PROFINET Scanner architectures.
NETWORK
PROFIBUS-DP V1
SLAVE CAPACITY
125 DEVICES
DATA RATE
9.6K–12M

COMMUNICATION CORE
The IC200BEM003 operates as a PROFIBUS-DP master. With a VersaMax CPU, it supports up to 3,584 bytes of input data and 3,584 bytes of output data; with a PROFINET Scanner head end, the maximum is 1,440 bytes in each direction.
IC200BEM003 / TECHNICAL PROFILE
Model IC200BEM003
Function PROFIBUS-DP Master Module
Protocol PROFIBUS-DP V1
Maximum Slaves 125 PROFIBUS-DP slave devices
Network Rate 9.6 Kbaud to 12 Mbaud
Power Consumption 450 mA at +5 V
CPU Data Capacity 3,584 bytes input / 3,584 bytes output
PNS Data Capacity 1,440 bytes input / 1,440 bytes output
Per-Slave Data Up to 244 bytes input / 244 bytes output
Connector 9-pin female DB9 PROFIBUS connector
Communication Modes Sync / Freeze / DP-V1 Read, Write & Alarm
Carrier IC200CHS006 Communications Carrier
◇
SYSTEM INTEGRATION / IC200BEM003
HOST
VersaMax CPU005 / CPUE05
 →
MASTER
IC200BEM003
 →
FIELD NETWORK
PROFIBUS-DP
Configuration note: The module can also be configured on a VersaMax PROFINET Scanner in an RX3i PROFINET system. The BEM003 requires a PNS version 1.10 or later in that arrangement.

VERSAMAX NETWORK MODULE FAMILY
IC200BEM002
PROFIBUS-DP Slave module for VersaMax network applications; it uses the IC200CHS006 communications carrier.
IC200BEM003
PROFIBUS-DP Master module for connecting supported VersaMax or PROFINET Scanner architectures with PROFIBUS-DP slave devices.
CONFIGURATION FIT
The module can occupy a module location in a VersaMax system when installed on the IC200CHS006 communications carrier.
NETWORK CONTROL
PROFIBUS station addressing, slave configuration, data mapping and diagnostic functions are configured through the supported control environment.
DIAGNOSTIC DESIGN
Module and network status LEDs, slave status bits and diagnostic functions support network-level troubleshooting.


AMIKON INDUSTRIAL AUTOMATION
Need IC200BEM003?
Send the exact part number together with your quantity and application requirements for a faster quotation.
✉ EMAIL · sales@amikon.cn ☎ WHATSAPP · 86-18020776792
Sales Manager: Miya zheng
IC200BEM003 / BUYER FAQ
Q1. Can IC200BEM003 be used when replacing an existing PROFIBUS-DP master in a VersaMax installation?
It can be considered for a VersaMax PROFIBUS-DP master replacement when the existing architecture uses the required communications carrier and a supported host arrangement. The BEM003 requires the IC200CHS006 communications carrier, so the carrier and host configuration should be checked together rather than treating the module as an independent plug-in replacement.
Q2. Is IC200BEM003 suitable for a PROFIBUS network with many existing slave nodes?
Yes, the module supports up to 125 PROFIBUS-DP slave devices. The practical configuration still depends on the selected network architecture, station addressing, segmentation and the data required by each slave. Each slave can have up to 244 bytes of input data and 244 bytes of output data.
Q3. What should be checked before ordering IC200BEM003 for an RX3i PROFINET architecture?
Confirm that the intended system uses a compatible PROFINET Scanner and that the PNS firmware requirement is satisfied. The BEM003 requires a PNS version 1.10 or later when configured as a module on a VersaMax PROFINET Scanner in an RX3i PROFINET system.
Q4. Does IC200BEM003 provide enough data capacity for a large PROFIBUS-DP configuration?
With a VersaMax CPU, the maximum mapped PROFIBUS data is 3,584 bytes of input data and 3,584 bytes of output data. When used with a PROFINET Scanner head end, the maximum is 1,440 bytes of input data and 1,440 bytes of output data. The applicable capacity therefore depends on the host architecture.
Q5. What installation detail should be checked when replacing IC200BEM003 in an operating cabinet?
IC200BEM003 does not support hot-swap installation or removal with power applied. Power should be removed before the module is installed on or removed from the communications carrier. The PROFIBUS connection also uses a standard female DB9 interface, and network termination must be provided by suitable bus hardware because the module does not contain built-in termination.
