GE FIELD CONTROL · DISCRETE INPUT
IC670MDL233120 VAC Isolated Discrete Input Module
Eight individually isolated input circuits acquire 120 VAC field states and transfer one byte of discrete input data through a Field Control Bus Interface Unit. |
AVAILABILITY DESK
Match the exact module
REQUEST A QUOTE → |
|
RATED VOLTAGE
120 VAC
|
INPUT RANGE
0–132 VAC
|
FREQUENCY
47–63 Hz
|
DATA SIZE
8 bits
|
|
ELECTRICAL PROFILE
Eight independent AC input pathsEach field point has its own input and neutral connection. Point-to-point isolation supports independent 120 VAC input circuits within the same module. 300 VAC
POINT-TO-POINT CONTINUOUS
|
INPUT CHARACTERISTICS
Defined switching thresholds
|
|
①
AC field state
A switch, relay contact or compatible AC device applies voltage to an input. |
→ |
②
Threshold filtering
Resistor and capacitor networks establish switching thresholds and filter the input. |
→ |
③
Optical isolation
Optoisolators separate field-input circuits from the module logic. |
→ |
④
BIU transfer
Eight buffered states are converted into serial form and read by the Bus Interface Unit. |
|
RESPONSE & ISOLATION
Timing suited to conventional AC devices
|
LOCAL INDICATION
Status visible at the stationEight circuit LEDs
Each LED represents the buffered ON/OFF state of one input.
PWR indicator
Illuminates when backplane power is present.
|
|
Typical system role
Used in GE Field Control stations to monitor 120 VAC limit switches, relay contacts, interlocks, permissives and machine-state circuits. |
Why teams search for it
Search activity often follows a missing input transition, a channel that remains ON or OFF, mismatched circuit indication or loss of the PWR LED. |
Downtime exposure
A lost permissive or interlock state can prevent startup, interrupt a sequence or hold equipment in a safe stopped condition. |
|
INSTALLATION CHECK
Preserve the isolated input arrangementEvery input uses its corresponding neutral terminal. Verify the complete field circuit before transferring conductors. |
|
|
BOX TERMINAL BLOCK
IC670CHS002 / 102
Separate input and neutral terminals for all eight channels.
|
BARRIER TERMINAL BLOCK
IC670CHS001 / 101
Can be paired with an auxiliary terminal block when more connection points are needed.
|
CONNECTOR TERMINAL BLOCK
IC670CHS003 / 103
Uses one 20-pin male connector for the installed module.
|
