| GE VERSAMAX IC200MDL744 | DETAILS | CONTACT | FAQ | AMIKON | RELATED MODELS |
|
OUTPUT TYPE
Negative / Sinking
|
POINT COUNT
32 Points
|
GROUPING
2 × 16 Outputs
|
MAX LOAD
0.5 A / Point
|
The GE Fanuc VersaMax IC200MDL744 is a discrete output module designed for control architectures requiring 32 digital output points. The module provides two independently grouped sets of 16 negative-logic, sinking outputs. An external DC supply powers the field loads, while the CPU or Network Interface Unit provides the output data to the module.
The module supports 5VDC-TTL operation as well as 12/24VDC operation. Each output has an individual green status indicator, while FLD PWR indicates field power and OK indicates backplane power. The two output groups each have dedicated DC+ and DC− terminals.
| 32 discrete output points | Two groups of 16 outputs |
| Negative / sinking logic | External DC field supply required |
| 5VDC-TTL mode | 12/24VDC operating mode |
| Individual output LEDs | FLD PWR and OK indicators |
| Optical isolation to logic | Group-to-group isolation |
| Parameter | IC200MDL744 |
| Module type | Discrete output module |
| Output logic | Negative logic / sinking outputs |
| Number of points | 32 points, 2 groups of 16 |
| Module ID | 80808080 |
| 5VDC-TTL supply range | +4.75 to +5.25VDC, +5VDC nominal |
| 12/24VDC supply range | +10.2 to +30VDC, +12/24VDC nominal |
| 5VDC-TTL load current | 25mA maximum |
| 12/24VDC load current | 0.5A at 30VDC maximum, resistive |
| Inrush current | 2.0A maximum for 100ms |
| Output voltage drop | 0.4V maximum in 5VDC-TTL mode; 0.3V maximum in 12/24VDC mode |
| Output leakage current | 0.5mA maximum at 30VDC |
| ON response time | 0.2ms maximum |
| OFF response time | 1.0ms maximum |
| Backplane current consumption | 5V output: 140mA maximum |
| Isolation | 250VAC continuous; 1500VAC for 1 minute for logic/frame and group-to-group isolation; no point-to-point isolation |
| Output protection | No internal fuses |
| Approx. module dimensions | 110 mm × 66.8 mm × 50 mm, excluding carrier height and mating connectors |
|
FIELD STRUCTURE
Two 16-Point Groups
Outputs 1–16 form the first group, while outputs 17–32 form the second group. Each group has its own DC+ and DC− field terminals. |
|
| Model | Output Arrangement | Logic / Rating | Selection Consideration |
| IC200MDL740 | 16 points / 1 group | 12/24VDC positive logic, 0.5A | For positive-logic applications with fewer output points. |
| IC200MDL741 | 16 points / 1 group | 24VDC positive logic, 0.5A with ESCP | A different output architecture with electronic short-circuit protection. |
| IC200MDL742 | 32 points / 2 groups | 5/12/24VDC negative logic, 0.5A | Closely related 32-point negative-logic option; verify the exact installed configuration before substitution. |
| IC200MDL744 | 32 points / 2 groups | 5/12/24VDC negative logic, 0.5A | Two grouped 16-point sinking output banks with 5V TTL and 12/24VDC modes. |
| IC200MDL750 | 32 points / 2 groups | 12/24VDC positive logic, 0.5A | Useful when the application requires positive rather than negative output logic. |
IC200MDL744 is suited to VersaMax control architectures where multiple discrete DC loads need to be switched from a 32-point output module. Typical loads can include contactors, indicator lamps and interposing relays, subject to the electrical characteristics of the connected load.
For inductive loads, external suppression should be considered. The output stage does not contain internal fuses, so external circuit protection and appropriate load protection should be evaluated as part of the installation.
During replacement, verify the negative/sinking output logic, field-voltage mode, carrier arrangement, two-group wiring and load current before installing another module. A visually similar 32-point module is not automatically a direct electrical substitute.
| Delivery | 3–5 days | Warranty | 12 months | Packaging | Brand New |
| Delivery Way | E-packing / FedEx / EMS / TNT / DHL / UPS | Payment | T/T | ||
|
Q1. Is IC200MDL744 a suitable replacement when an existing VersaMax system uses 32 sinking outputs?
It can be appropriate when the existing installation requires the same 32-point, two-group negative/sinking output architecture and the field-voltage requirements match. Before replacement, verify the carrier, group wiring, external supply range, connected load current and system configuration. A 32-point count by itself does not establish electrical interchangeability.
|
|
Q2. What should a buyer verify before ordering IC200MDL744 for a 24VDC output application?
Verify that the application uses negative/sinking outputs, that the external field supply falls within the 12/24VDC operating range of +10.2 to +30VDC, and that each resistive load is within the 0.5A maximum rating at 30VDC. The two field groups should also match the existing wiring arrangement.
|
|
Q3. Why might IC200MDL744 be considered instead of IC200MDL750 in a replacement project?
The key distinction is output logic. IC200MDL744 uses negative/sinking logic and supports 5V TTL as well as 12/24VDC operation, while IC200MDL750 is a positive-logic 12/24VDC output module. The installed control design and field wiring should determine which architecture is appropriate.
|
|
Q4. What should be checked if an IC200MDL744 output LED changes but the connected load does not operate?
Check the field supply, the relevant DC+ and DC− group terminals, output wiring, load condition and the electrical characteristics of the load. The module's output indicators are driven from the backplane and their operation depends on valid field power rather than directly on the load condition. For inductive loads, appropriate external suppression should also be evaluated.
|
|
Q5. Is IC200MDL744 preferable for applications that need 5V TTL output capability as well as 12/24VDC operation?
IC200MDL744 specifically provides both operating modes. In 5VDC-TTL mode, the output range is +4.75 to +5.25VDC with a 25mA maximum load current. In 12/24VDC mode, the operating range is +10.2 to +30VDC, with a maximum resistive load rating of 0.5A at 30VDC. The actual selection should follow the installed load and control architecture.
|
