The IC200ALG230 is a VersaMax analog input module providing four single-ended analog channels. The channels can interface with voltage or current field signals, with voltage operation supporting bipolar ±10 VDC or configurable unipolar 0–10 VDC, and current operation supporting 4–20 mA.
BUYER'S CHECKPOINT
What matters before replacement?
Signal type
Voltage / 4–20 mA
Channels
4
Resolution
12 bit
Configuration
Carrier jumpers
External module supply
Not required
CHANNEL COUNT
4
RESOLUTION
12 bit
UPDATE RATE
0.4 ms
FILTER
5.0 ms
BACKPLANE
125 mA max.
01 / PRODUCT ROLE
Designed around signal compatibility
IC200ALG230 is intended for VersaMax distributed I/O architectures where four analog field signals must be brought into the control system. All four inputs are single-ended and share a common return. The module receives its operating power from the backplane, so a separate external supply is not required for the module itself.
For a replacement purchase, the important configuration point is not only the catalog number. The carrier jumper arrangement determines whether the module operates in voltage or current mode, and voltage mode can be configured for bipolar or unipolar operation. A field installation therefore needs to be checked against the intended signal type before the module is installed.
The module provides four words of analog input data. Processing is performed by the CPU or NIU, while the module provides local status indication through the INT PWR and OK LEDs.
01
Four Analog Channels
Four single-ended channels in one input group.
02
Three Signal Ranges
±10 VDC, 0–10 VDC and 4–20 mA operation.
03
Fast Data Refresh
0.4 ms module update rate with 5 ms filtering.
04
Local Status
INT PWR and OK indicators assist field checks.
SPEC
02 / TECHNICAL CORE
Specification Map
The electrical configuration is centered on four single-ended analog channels and carrier-based jumper selection.
Module type
12-bit analog input, voltage/current
Channels
4 single-ended channels, one group
Voltage input
±10 VDC bipolar default; 0–10 VDC configurable
Current input
4–20 mA
Voltage input impedance
126 kΩ maximum
Current input impedance
200 Ω maximum
Voltage resolution
2.5 mV = 8 counts
Current resolution
4 µA = 8 counts
Filter response
5.0 ms
Update rate
0.4 ms per module
Accuracy at 25°C
±0.3% typical, ±0.5% maximum of full scale
Accuracy, 0–60°C
±1% maximum of full scale
Backplane consumption
125 mA maximum at 5 V output
External supply
None for module operation
Diagnostic
Loss of internal power
03 / CONFIGURATION LOGIC
The replacement check that matters
Carrier jumpers determine the operating mode.
One carrier jumper selects voltage or current operation. In current mode, the module accepts 4–20 mA. With the current-mode jumper absent, voltage operation is used, with ±10 VDC as the default range. A second carrier jumper can select the 0–10 VDC range for voltage operation.
INSTALLATION DECISION
Confirm the existing carrier, signal type and jumper arrangement before replacing an installed module. Voltage and current devices can be connected per channel, but not both on the same channel.
04 / FIELD USE
Where IC200ALG230 fits
The module is suited to VersaMax control installations that need a compact four-channel analog interface for transmitter, sensor or other industrial analog signals represented by 4–20 mA, ±10 VDC or 0–10 VDC.
Because the four channels share a common return and are single-ended, the existing field wiring arrangement should be checked before ordering a replacement. The module is particularly relevant when maintaining an existing VersaMax architecture where retaining the established four-channel analog layout is important.
When a field issue appears
No field signal
Check the selected input mode, carrier jumper arrangement, common return and field wiring.
INT PWR issue
The INT PWR indicator relates to internally generated field-side power.
OK LED off
The OK indicator represents the presence of backplane power at the module.
05 / VERSAMAX ANALOG FAMILY
Choose by channel and signal architecture
Model
Core configuration
Why it matters in selection
IC200ALG230
12-bit, voltage/current, 4 channels
Four-channel mixed voltage/current interface
IC200ALG240
16-bit, voltage/current, isolated, 8 channels
Higher resolution and eight-channel isolated architecture
IC200ALG260
12-bit, voltage/current, 8 channels
Same 12-bit class with double the channel count
IC200ALG261
15-bit differential voltage, 8 channels
Differential voltage architecture rather than the IC200ALG230 single-ended arrangement
IC200ALG262
15-bit differential current, 8 channels
Designed around differential current acquisition
06 / DIRECT SALES DESK
Need IC200ALG230?
Send the exact part number and system details before placing an order. This helps us check the required configuration and replacement requirements.
Q1. Can IC200ALG230 replace an existing four-channel VersaMax analog input module directly?
It is designed as a four-channel VersaMax analog input module, but replacement should be checked against the existing carrier arrangement and field signal configuration. The IC200ALG230 uses carrier jumpers to select voltage/current operation and voltage range, so the existing installation should be checked rather than treating the module number alone as the complete replacement condition.
Q2. Is IC200ALG230 suitable when the existing field devices use 4–20 mA?
Yes. The current-input configuration accepts 4–20 mA. The carrier jumper must be arranged for current operation. The current input impedance is specified as 200 Ω maximum, and the module provides 4 µA resolution per 8 counts.
Q3. Why should the carrier jumper configuration of IC200ALG230 be checked before shipment?
Because the module's operating mode is selected at the carrier. One jumper determines voltage or current operation, while another can select the 0–10 VDC voltage range. A replacement that arrives with an incorrect configuration can require field reconfiguration before the connected signal can be handled correctly.
Q4. Does IC200ALG230 need a separate external power supply?
No external power supply is required for the module itself. The module receives power from the VersaMax backplane. The specified backplane current consumption is 125 mA maximum at the 5 V output. Power for user transceivers, when required by the field application, is separate.
Q5. What should be checked if an IC200ALG230 installation loses its expected analog reading?
First verify the selected signal mode and carrier jumper arrangement, then check the common return and field wiring. The INT PWR LED indicates internally generated field power, while the OK LED indicates backplane power at the module. The module also reports a Loss of Internal Power diagnostic.
IC200ALG230 replacement note
For maintenance purchasing, provide the installed signal type, carrier arrangement and machine/system application together with the part number. This allows the replacement requirement to be checked around the actual installation rather than only around the model number.
