GE · MARK V SERIES
SHUNT ISOLATOR BOARD
DS200SVIAG1A
A Mark V board associated with shunt signal isolation, circuit test points and adjustable signal-conditioning hardware.
|
 PART IDENTIFICATION · TEST-POINT CHECK · ORDER CONFIRMATION
|
|
PLATFORM
Mark V
|
BOARD TYPE
SVIA
|
TERMINALS
7 + 8 Positions
|
ADJUSTMENT
3 Potentiometers
|
| 01 |
Product Overview
SHUNT SIGNALS · ISOLATION · CIRCUIT TESTING
|
The GE DS200SVIAG1A is identified as a Shunt Isolator Board associated with the Mark V control family. Its visible hardware includes two terminal blocks, one with seven terminals and the other with eight, multiple test points, two jumpers, one LED and three potentiometers.
The board's test points provide access for circuit checks, while its adjustable components support specific signal-conditioning functions. Labels such as VIN, ACOMTS, TEST, SOURCE, P15IS and VIN1 may be present on the board. These labels should be read directly from the installed assembly before measurements or adjustments are made.
| Manufacturer | GE (General Electric) |
| Part Number | DS200SVIAG1A |
| Functional Name | Shunt Isolator Board |
| Associated Platform | Mark V |
| Terminal Blocks | Two blocks: 7-terminal and 8-terminal groups |
| Adjustable Hardware | Two jumpers and three potentiometers |
| Test Access | Multiple labeled test points |
| Board Revisions | Revision details must be confirmed from the installed board label |
| 02 |
Board Features & Maintenance Role
TERMINAL CONNECTIONS · TEST POINTS · ADJUSTMENT
|
|
01 · CONNECTIONS
Two Terminal Blocks
Seven terminals on one block and eight on the other provide the board's visible terminal interface.
|
02 · TESTING
Labeled Test Points
Designated points allow qualified personnel to check selected circuit conditions using suitable test equipment.
|
03 · ADJUSTMENT
Jumpers & Pots
Two jumpers and three potentiometers form part of the board's configurable or adjustable hardware.
|
| DS200SVIAG1A
Mark V Shunt Isolator Board, with terminal blocks, test points and adjustment hardware.
|
DS200NATOG2A
LS2100 voltage feedback scaling board, with five resistor strings and a 20-pin ribbon output connection.
|
| 03 |
Replacement & Inspection Checklist
CONFIRM THE HARDWARE BEFORE INSTALLATION
|
| 01 · Part label
Check the full DS200SVIAG1A model and visible revision markings on the actual board.
|
02 · Terminal layout
Compare both terminal blocks and their signal labels against the installed wiring arrangement.
|
| 03 · Jumpers & pots
Record the existing jumper positions and adjustment settings before authorized removal.
|
04 · Test points
Use the board's actual labels and the equipment-specific testing procedure for any measurements.
|
Do not adjust potentiometers or change jumper positions solely to make a replacement look like another revision. Follow the applicable commissioning or maintenance procedure and use qualified personnel.
|
PART MATCHING & AVAILABILITY
Looking for DS200SVIAG1A?
Send the complete part number, required quantity, destination and required date. A clear label photo and images of the terminal and adjustment areas can help verify the requested assembly.
|
Miya Zheng · Sales Manager
Email: sales@amikon.cn
Phone / WhatsApp: +86 180 2077 6792
|
| Delivery
Typically 3–5 days, subject to confirmation
|
Warranty
12 months, subject to order terms
|
Payment
T/T
|
Shipping
DHL / UPS / FedEx / EMS / TNT
|
 |
 |
 |
| Broad product range
Industrial automation parts
|
Order coordination
Tracking and communication
|
Global dispatch
Shipping options by destination
|
| 04 |
DS200SVIAG1A — Frequently Asked Questions
IDENTIFICATION · TERMINALS · MAINTENANCE
|
AMIKON supports industrial customers sourcing automation parts for maintenance, repair and equipment continuity. Share the exact model, quantity, destination and required date to help the team confirm the most relevant supply option.
