Product Details

FOXBORO | FBM

OVERVIEW SPECS CONTACT FAQ RELATED PARTS

FOXBORO 200 SERIES / FIELD CONTROL

RH927BN

FBM247 Current / Voltage
Analog, Digital & Pulse I/O

The RH927BN is the Foxboro FBM247 module, providing eight individually configurable and galvanically isolated I/O channels. Each channel can be configured for analog, digital or pulse applications, with HART-compatible 4–20 mA operation.

CHANNEL ARCHITECTURE

Individually configurable I/O channels

FIELD SIGNALS

AI / AO / DI / DO

Pulse & HART supported

ACCURACY

0.03%

Analog input span

RESOLUTION

16 bit

Analog input conversion

FIELD POWER

24 VDC

+5% / −10%

Technical Profile

A configurable FBM247 architecture designed for mixed analog, discrete and pulse field I/O.

SIGNAL & I/O CAPABILITY
Analog Input	0–20 mA; 0–10 V; 0–5 V; HART 4–20 mA
Analog Output	0–20 mA / HART 4–20 mA
Digital I/O	24 VDC contact / voltage sensing and output
Pulse	Pulse count, frequency, acceleration or jerk

PERFORMANCE & PHYSICAL DATA
Input Accuracy	0.03% of span
Analog Input Resolution	16 bits
Module Dimensions	102 × 45 × 104 mm
Module Weight	Approx. 373 g
Operating Temperature	−20 to +70 °C

CONFIGURATION FLEXIBILITY

Each channel can be independently configured without taking the module or other channels offline. The module supports HART instruments compliant with HART versions 5, 6 and 7. HART communication can pass universal, common-practice and device-specific commands, while burst communication mode is not supported.

AMIKON INDUSTRIAL AUTOMATION

Need RH927BN?

Send the complete part number together with your project requirements for a faster quotation.

EMAIL sales@amikon.cn	PHONE / WHATSAPP 86-18020776792
Sales Manager: Miya zheng \| Delivery: 3–5 Days \| Warranty: 12 Months
Brand New Packaging • E-packing / FedEx / EMS / TNT / DHL / UPS • Payment: T/T

QUOTE CHECKPOINT

To match the correct configuration and delivery requirement, please include the following details with your inquiry.

Part Number

Quantity

Destination

Required Date

Machine/System

PURCHASING & APPLICATION FAQ

RH927BN — Five Practical Questions

Can RH927BN replace several different 200 Series I/O module types in a mixed-signal application? RH927BN can reduce the number of separate 200 Series FBM types required for spare coverage because its eight channels can be configured for analog, digital and pulse applications.	What should be checked before ordering RH927BN for an existing Foxboro installation? Confirm the 200 Series baseplate arrangement, termination assembly choice, system software compatibility and field-signal configuration. RH927BN is specified for I/A Series software v8.7–v8.8 and Foxboro Evo Control Core Services v9.0 or later.
How does RH927BN handle HART devices when the plant uses standard 4–20 mA loops? The HART-capable channels are electrically compatible with standard 4–20 mA inputs. RH927BN can act as a HART field-device host and communicate with compatible HART instruments.	Is RH927BN suitable when signal types may change during a project or retrofit? Yes. Its channel architecture is intended for situations where the final signal mix is not fully established early in a project. Each channel can be independently configured for supported signal types.
What makes RH927BN useful when replacement downtime must be kept short? The FBM247 design allows the module to be removed and replaced without removing field-device termination cabling or power and communications cabling. This architecture can simplify replacement work during maintenance.
