RH916XG is the compression-terminal termination assembly used with the Compact FBM201. In the Compact 200 Series architecture, the termination assembly provides the field connection point between process wiring and the FBM subsystem.
The corresponding Compact FBM201 arrangement is designed for eight channels of 0 to 20 mA DC input with passive feedthrough and channel isolation. RH916XG is therefore best considered as part of the complete I/O interface rather than as a stand-alone analog processing module.
|
01 / FIELD CONNECTION
Compression terminal interface
|
02 / SIGNAL RANGE
0 to 20 mA DC input arrangement
|
03 / SYSTEM ROLE
Compact FBM201 termination
|
|
SALES MANAGER
Miya zheng
CONTACT SALES |
EMAIL
sales@amikon.cn
SEND EMAIL |
PHONE / WHATSAPP
86-18020776792
CHAT ON WHATSAPP |
|
TECHNICAL PROFILE
SpecificationsThe RH916XG termination assembly is matched to the Compact FBM201 interface. Its principal role is field termination for the specified 0 to 20 mA DC input arrangement. |
|
|
DESIGN POINTS
Why RH916XG?Matched termination architecture
Designed around the Compact FBM201 0 to 20 mA DC input arrangement.
Eight-channel field interface
Provides the field-side termination point for the eight-channel Compact FBM201 input configuration.
Compression termination
The RH916XG configuration uses compression terminals for field wiring.
|
APPLICATION FIT
Where It MattersRH916XG is appropriate when maintaining or expanding a Compact 200 Series I/O installation built around FBM201 analog input channels. It is particularly relevant when a termination assembly needs to match the existing Compact FBM201 field interface rather than introducing a different termination arrangement. Replacement consideration: Verify the FBM type, input range, terminal arrangement and cable interface before substituting another termination assembly.
|
Within the Compact 200 Series, termination assemblies are selected according to the associated FBM and signal architecture. RH916XG is the compression-terminal choice associated with Compact FBM201 for 8-channel 0 to 20 mA DC passive feedthrough.
| Termination Assembly | Associated FBM | Signal Configuration | Terminal Type |
|---|---|---|---|
| RH916XG | Compact FBM201 | 8 × 0–20 mA DC | Compression |
| RH922ZM | Compact FBM201b | 8 × 0–100 mV DC | Compression |
| RH922ZN | Compact FBM201c | 8 × 0–5 V DC | Compression |
| RH922ZP | Compact FBM201d | 8 × 0–10 V DC | Compression |
|
DELIVERY
3–5 Days
|
WARRANTY
12 Months
|
PACKAGING
Brand New
|
PAYMENT
T/T
|
|
Can RH916XG be selected when replacing a Compact FBM201 termination assembly?
Yes, when the existing installation uses Compact FBM201 with the 0 to 20 mA DC passive-feedthrough configuration and the required compression-terminal arrangement.
|
What should be checked before ordering RH916XG for an existing cabinet?
Confirm the installed FBM type, 0 to 20 mA signal configuration, termination style and cable interface. These details determine whether RH916XG matches the existing I/O arrangement.
|
|
Why choose RH916XG instead of another Compact 200 Series termination assembly?
RH916XG is specifically aligned with Compact FBM201 0 to 20 mA DC inputs. Other termination assemblies in the series correspond to different FBM variants or signal configurations.
|
Does RH916XG itself perform analog signal conversion?
RH916XG is a termination assembly. The signal-processing role belongs to the associated FBM201 interface; RH916XG provides the field termination connection.
|
|
When is RH916XG the safer purchasing choice for a maintenance replacement?
It is the appropriate choice when the existing Compact FBM201 installation requires the documented 0 to 20 mA DC termination arrangement with compression terminals. Matching the installed architecture is more important than selecting a visually similar terminal assembly.
|
|
 |
