Product Details

FOXBORO · FIELDBUS INTERFACE

FBM246

FoxCom™ Redundant Dual Baud Rate Intelligent Device Interface

Digital communication built around redundant field-device connectivity

Foxboro FBM246 is a redundant intelligent device interface built around eight individual FoxCom communication channels. Each channel provides bidirectional digital communication with a Foxboro Intelligent Field Device, while channel isolation separates the individual field loops.

The module pair supports independently configured 600 or 4800 baud operation. At 4800 baud, messages are received at up to ten times per second; at 600 baud, the rate is up to two messages per second. The architecture also supports internal isolated field-device power or an external power arrangement.

CHANNELS 8 isolated FoxCom channels	BAUD RATE 600 / 4800 baud, independently set
FIELD LINK 2-WIRE single twisted pair	FIELD POWER 23.1–25.3 V DC internal isolated supply

01 / ARCHITECTURE

A redundant path for every field-device connection

◇

FBM A

Module path A

↔

COMMON TERMINATION

REDUNDANT ADAPTER + TA

One field wiring interface serving the redundant module pair

↔

◇

FIELD

Intelligent field devices

FoxCom communication

Communication is point-to-point, master/slave, asynchronous and half-duplex. Each channel can independently operate at 600 or 4800 baud according to the connected field-device configuration.

4800 baud: up to 10 messages per second
600 baud: up to 2 messages per second

Field-device data handling

Digital messages can contain up to three measured variables in IEEE 32-bit floating-point format together with security data, diagnostics and message checking. The bidirectional link also supports device-related values and configurable device attributes.

Output values · Fail-safe status · Tag details · Device name · Last calibration date · Upload/download functions

REQUEST FBM246 CHAT WITH SALES

02 / TECHNICAL PROFILE

FBM246 at a glance

Field interface	8 isolated and independent FoxCom communication channels
Communication	Point-to-point, master/slave, asynchronous, half-duplex
Selectable baud rate	600 or 4800 baud; each channel independently configurable
Error checking	CCITT 2-byte CRC
Field communication distance	600 m at 4800 baud with shielded twisted pair; 1800 m at 600 baud
Wire reference	0.50 mm² (22 AWG) shielded twisted pair recommended for the stated maximum distances
Compliance voltage	19 V DC minimum at 20.5 mA
Maximum loop resistance	Up to 400 Ω with Intrinsic Safety Barrier; up to 330 Ω without Intrinsic Safety Barrier
FBM input impedance	200 Ω nominal
Field-device internal power	23.1 to 25.3 V DC; source resistance 200 Ω
Module fieldbus	Redundant 2 Mbps module Fieldbus via associated FCM or FCP
Power input	24 V DC +5%, -10% redundant supply
Power consumption	10 W maximum per redundant pair
Heat dissipation	6 W maximum per redundant pair
Operating temperature	-20 to +70°C (-4 to +158°F)
Operating humidity	5 to 95%, noncondensing
Operating altitude	-300 to +3,000 m (-1,000 to +10,000 ft)
Storage temperature	-40 to +70°C (-40 to +158°F)
Vibration	7.5 m/s² (0.75 g) from 5 to 500 Hz

03 / MAINTENANCE

Designed around replaceable module pairs

A redundant FBM246 pair uses a common field termination arrangement. Either module can be removed and replaced without removing the field-device termination cabling, power or communication cabling connected to the healthy module.

Module status: front-panel LEDs provide visual indication of operating condition and communication activity.

Baseplate & termination arrangement

FBM246 modules mount on a Modular Baseplate that can be DIN-rail mounted horizontally or vertically, or rack mounted horizontally with the appropriate mounting kit. A redundant pair occupies adjacent baseplate positions.

Termination assemblies provide the field wiring interface. Non-intrinsically safe and intrinsically safe arrangements are available, with the appropriate termination assembly and field protection arrangement selected for the installation.

Termination cable lengths are available up to 30 m (98 ft), allowing the termination assembly to be positioned in the same or an adjacent enclosure.

04 / SYSTEM FIT

Where FBM246 makes practical sense

Digital device integration

Useful where FoxCom intelligent field devices need bidirectional digital communication with the control system.

Redundant I/O architecture

The paired-module arrangement keeps the field wiring connected through a common termination path.

Mixed communication rates

Independent channel baud selection allows different connected devices to operate at their configured rate.

Maintenance-sensitive loops

The removable module architecture supports maintenance work while retaining the field termination arrangement.

05 / RELATED FAMILY

FBM246 family positioning

FBM243

Provides eight FoxCom intelligent device interface channels with dual baud-rate capability in a non-redundant module arrangement.

FBM246

Uses a redundant pair of modules with eight isolated FoxCom communication channels for intelligent field-device connectivity.

FBM246b

Combines four dual-baud FoxCom communication channels with four 0–20 mA analog output channels in the redundant module arrangement.

When replacing an existing installation, confirm the exact FBM variant, baseplate position, termination assembly, redundant adapter and field-device arrangement before ordering.

DELIVERY

3–5 Days

WARRANTY

12 Months

PACKAGING

Brand New

PAYMENT

T/T

Delivery way: E-packing / FedEx / EMS / TNT / DHL / UPS

06 / DIRECT CONTACT

Need FBM246 for an urgent replacement?

Send the part details and application requirements for a faster quotation.

EMAIL · sales@amikon.cn

PHONE / WHATSAPP · 86-18020776792

SALES MANAGER · MIYA ZHENG

For quotation, please provide: Part Number · Quantity · Destination · Required Date · Machine/System

07 / BUYER QUESTIONS

FBM246 — Five practical questions before replacement

01	Can FBM246 be considered when an existing redundant FoxCom interface needs a direct module replacement? Yes, when the existing architecture is built around the FBM246 function and its associated redundant baseplate, adapter and termination arrangement. Before ordering, the complete field-side configuration should be checked because the module is part of a larger redundant I/O path rather than an isolated field component.
02	Why does the FBM246 replacement require attention to the termination assembly? The field wiring reaches the redundant FBM pair through the termination arrangement and redundant adapter. Different termination assemblies support non-intrinsically safe or intrinsically safe installations, so matching the module alone does not guarantee the correct field-side configuration.
03	Does FBM246 support field devices operating at different FoxCom baud rates? Yes. Each channel can independently use either 600 or 4800 baud according to the configuration of the connected field device. This allows different channels on the same FBM246 arrangement to operate at their respective configured rates.
04	What should be checked when an FBM246 loop uses an external power supply? A common external supply used by multiple loops requires a Cable Balun Module to maintain digital communication line balance. The balun arrangement is not required for loops powered by the FBM246 internal isolated supply. The field loop resistance and available compliance voltage also need to remain within the specified operating limits.
05	Can one FBM246 module be replaced without disconnecting the field termination wiring? The redundant architecture is designed so either module can be removed and replaced without removing the field-device termination cabling, power or communication cabling from the healthy module. Plant operating conditions should still be considered before carrying out the replacement.

08 / AMIKON INDUSTRIAL SUPPORT

Parts, service and speed for industrial continuity

Keeping hard-to-find automation components moving

Amikon focuses on the automation components that help manufacturing facilities keep their control systems operating. The goal is straightforward: shorten the time between identifying a required component and getting the replacement moving toward the plant.

Built around practical purchasing needs

From widely used automation components to difficult-to-source industrial parts, our service is organized around availability, response speed and shipment coordination for customers around the world.

Global delivery · Automation components shipped to customers worldwide
Spare-parts support · Practical assistance for maintenance and replacement requirements
Broad manufacturer coverage · Components from more than 100 automation manufacturers
Large transaction volume · More than ten million industrial parts sold worldwide

Find it. Move it. Get your system running.

Amikon works to locate and deliver the components required to support industrial automation maintenance, regardless of how long a part has been in service, how difficult it is to source, or where the equipment is installed.
