EMERSON DELTAV S-SERIES
KJ3231X1-BK1
S-Series Isolated Input Card
The KJ3231X1-BK1 is an S-Series isolated input card for the DeltaV system. It provides an isolated interface for up to four sensors and is implemented as a pluggable module that mates with an S-Series I/O Interface Carrier and a dedicated I/O Terminal Block. |
|
|
01 / CORE ARCHITECTURE
A compact isolated interface inside the S-Series architecture
The card is designed as a pluggable DeltaV S-Series module. Its electrical and mechanical arrangement places the card between the S-Series I/O carrier and the field termination assembly, allowing the field-side sensor interface to be handled through the corresponding terminal block. |
Four-sensor isolated interface
The KJ3231X1-BK1 provides an isolated interface for up to four sensors. This makes the module distinct from the higher-density S-Series analog input cards used for large groups of conventional 4–20 mA signals. Two-board S-Series construction
The module uses two printed circuit boards together with an LED board inside an S-Series enclosure. The card obtains its operating power from the I/O Carrier. |
|
04
Sensor Interfaces
|
12 VDC
Local Bus Rating
|
350 mA
Local Bus Current
|
C2
Terminal Key
|
IP20
Protection Rating
|
| Product Type | S-Series Isolated Input Card | System | Emerson DeltaV |
| Input Interface | Isolated sensor interface | Sensor Capacity | Up to four sensors |
| Local Bus Power | 12 VDC at 350 mA | Carrier Interface | S-Series I/O Interface Carrier |
| Terminal Interface | Dedicated I/O Terminal Block | Terminal Key | C2 |
| Ambient Temperature | -40°C to +70°C | Relative Humidity | 5% to 95%, non-condensing |
| Shock | 10 g half-sine for 11 ms | Airborne Contaminants | ISA-S71.04-1985 Class G3 |
| Vibration | 1 mm peak-to-peak, 5–16 Hz; 0.5 g, 16–150 Hz | Ingress Protection | IP20 |
|
03 / SIGNAL PATH
Carrier → Card → Terminal → Sensor
|
|
|
KJ3231X1-BK1
Focused on isolated sensor interfacing with a capacity of up to four sensors. Its architecture is different from the higher-channel-count S-Series cards used for conventional discrete or 4–20 mA signal concentration.
|
KJ3222X1-BK1
An S-Series 8-channel analog input card designed for 4–20 mA signals with optional HART functionality. It is therefore aimed at a different signal class and channel-density requirement.
|
KJ3223X1-BK1
An S-Series 16-channel 4–20 mA HART analog input card. Compared with KJ3231X1-BK1, its emphasis is higher-density current-loop acquisition rather than the four-sensor isolated-input architecture.
|
|
KJ3231X1-BK1
Isolated / up to 4 sensors
|
KJ3222X1-BK1
8-channel / 4–20 mA / HART
|
KJ3223X1-BK1
16-channel / 4–20 mA / HART
|
KJ3224X1-BK1
8-channel / thermocouple-mV
|
|
05 / ENGINEERING VIEW
What matters when matching the card
Sensor count
The architecture is intended for up to four sensor interfaces, making channel count a primary selection point.
Isolation requirement
The card is specifically identified as an isolated input card. This distinguishes it from standard high-density analog-input alternatives.
Terminal matching
The corresponding isolated-input terminal block uses C2 keying. Correct keying is part of the mechanical compatibility arrangement.
|
Environmental operating envelope
|
|
06 / DIRECT SUPPORT
Need KJ3231X1-BK1?
Send the exact part number together with your required quantity, destination and required date. We can also help check related DeltaV S-Series requirements when the application needs a different input type or channel density. |
AMIKON LIMITED
|
Please contact us within 7 days if you have any question after you receiving the items.
The returned items has to be in its original condition, with a specific reason for the return. We will issue a return or replacement for your order after we received the returns.
The buyer is responsible for all the shipping cost incurred.
|
Can KJ3231X1-BK1 replace a higher-density S-Series analog input card?
Not as a like-for-like channel replacement. KJ3231X1-BK1 is an isolated-input card for up to four sensors, while KJ3222X1-BK1 provides eight 4–20 mA inputs and KJ3223X1-BK1 provides sixteen 4–20 mA HART inputs. The correct choice therefore depends on the sensor interface and required channel density. |
What terminal-block key should be matched with KJ3231X1-BK1?
The isolated-input terminal block is specified with key position C2. The card and terminal-block keying arrangement is important because the rotary keying system is intended to prevent an incompatible card and terminal block from being installed together. |
|
Does KJ3231X1-BK1 need power from the field side?
The card obtains power from the S-Series I/O Carrier. Its specified local-bus rating is 12 VDC at 350 mA. Field wiring is terminated through the associated I/O Terminal Block rather than by treating the card as a standalone instrument. |
Is KJ3231X1-BK1 suitable when the installation has a wide temperature range?
The specified ambient operating range is -40°C to +70°C. Installation still has to respect the complete system enclosure, hazardous-area requirements where applicable, and the environmental limits of the associated carrier and terminal assembly. |
|
What should a buyer verify before ordering KJ3231X1-BK1 for an existing DeltaV S-Series installation?
The critical checks are the exact part number, S-Series architecture, required sensor type and quantity, matching isolated-input terminal block, C2 key position, available carrier position, and environmental requirements. If the existing application is actually based on 4–20 mA HART channels, KJ3222X1-BK1 or KJ3223X1-BK1 belongs to a different signal architecture and should be evaluated instead. |
|
