EMERSON KJ3001X1-BJ1 12P0555X152 High Side Discrete Output Module

Contact us

Miya zheng

sales@amikon.cn

86-18020776792

Output Channels

8 Channels

Output Voltage

24 VDC

Output Current

500 mA per Channel

LocalBus Power Rating

12 VDC, 45 mA

Bussed Field Power Rating

60 VDC (24 VDC Nominal), 6 A/Card

Isolation Voltage

1500 V RMS

Operating Temperature

-30°C to +60°C

Storage Temperature

-40°C to +85°C

Humidity

5%–95% RH Non-Condensing

Power Consumption

5 W

Country of Origin

USA

Protection Features

Overcurrent & Short-Circuit Protection

Warranty

12 Months

u High-side discrete output architecture for industrial control systems.

u 8-channel output design for multiple field device connections.

u Supports 24 VDC output control applications.

u Electrical isolation improves system safety and signal integrity.

u Built-in short-circuit and overcurrent protection.

u Compact module structure for easy cabinet installation.

u Compatible with Emerson DeltaV DCS platforms.

u Suitable for harsh industrial operating environments.

u High reliability and long service life for continuous process operation.

The KJ3001X1-BJ1 module is used to:

u Control relays, solenoids, contactors, and actuators.

u Operate alarms and indicator devices.

u Provide discrete output signals from DeltaV controllers.

u Interface automation systems with field equipment.

u Execute process control commands in industrial plants.

u Support equipment start/stop and switching operations.

u Oil & Gas Industry

Controls valves, shutdown systems, pumps, compressors, and safety equipment in upstream and downstream facilities.

u Power Generation Plants

Provides output control for turbines, generators, circuit breakers, and auxiliary power systems.

u Chemical & Petrochemical Processing

Operates process equipment, emergency shutdown devices, and automated production systems.

u Water & Wastewater Treatment

Controls pumps, motorized valves, dosing systems, and plant alarm functions.

u Manufacturing & Industrial Automation

Supports production lines, packaging machinery, conveyor systems, and robotic equipment.

u Pharmaceutical & Food Processing

Ensures precise output control for regulated manufacturing environments and automated process equipment.

1. What is the primary function of the EMERSON KJ3001X1-BJ1?

The module provides discrete output control for field devices within Emerson DeltaV automation systems.

2. How many output channels does the KJ3001X1-BJ1 support?

The module provides 8 digital output channels for controlling multiple field devices simultaneously.

3. What output voltage does the module use?

The KJ3001X1-BJ1 is designed for 24 VDC output applications.

4. Does the module provide electrical isolation?

Yes. The module includes 1500 V RMS electrical isolation to improve protection against electrical noise and voltage surges.

5. Which industries commonly use the KJ3001X1-BJ1?

It is widely used in oil & gas, power generation, chemical processing, water treatment, pharmaceutical production, and industrial automation systems.
