| EMERSON · EZ1080-09-00-010 | PRODUCTSYSTEM FITSUPPLYFAQMODELS |
|
EMERSON AMS · EZ1000
EZ1080
|
| 8 mm probe family |
0 shaft contact |
3 matched elements |
| 01 | Product type | 8 mm eddy-current sensor |
| 02 | Series | Emerson AMS EZ1000 |
| 03 | Measurement role | Non-contact observation of conductive targets for relative shaft vibration or position applications |
| 04 | Order identity | EZ1080-09-00-010 |
| 05 | System construction | Sensor operates with the specified extension cable and signal converter or driver |
| 06 | Target requirement | Conductive target material and prepared measurement surface |
| 07 | Mounting check | Thread, unthreaded length, total probe length, connector and cable option must match |
| 08 | Gap setup | Set the mechanical gap within the linear operating region of the complete system |
| 09 | Cable practice | Route away from damage and electrical interference; secure without sharp bends |
| 10 | Commissioning | Confirm system sensitivity, gap voltage, polarity and monitor scaling before service |
| Send the complete probe code and matched-system details. | ASK MIYA |
|
01
EZ1080-09-00-010
8 mm EZ1000 sensor; exact mechanical code
Selected field sensor
|
02
EZ1080-04-00-010
Related 8 mm sensor order code
Different mechanical configuration
|
03
EZ1900 family
Extension/interconnect element
Completes the sensor-to-driver path
|
04
Signal converter
Conditions the eddy-current response
Provides usable voltage to the monitor
|
|
◎
20 Years of Automation Supply
Long-standing sourcing experience for current and difficult-to-find industrial parts. |
Emergency Dispatch
Quick action for downtime pressure. |
◇
Exact-Part Help
Share the full code and installation details. |
| Contact us within seven days if a concern appears after receipt. | Keep the item in its original condition and state the reason. Resolution follows return receipt and inspection. | Return-related shipping costs are paid by the buyer. |
| 1 |
EZ1080-09-00-010 — Can EZ1080-09-00-010 be matched only by its 8 mm probe diameter?
No. Match the entire order code, mechanical dimensions, mounting thread, cable and connector option, total system length and associated converter.
|
|
| 2 |
EZ1080-09-00-010 — Does EZ1080-09-00-010 operate as a stand-alone sensor?
It forms part of a calibrated eddy-current measurement chain with the specified interconnection and signal-conditioning components.
|
|
| 3 |
EZ1080-09-00-010 — What target conditions affect EZ1080-09-00-010 performance?
Target material, surface finish, geometry, runout and probe alignment affect the response. Commission the installed channel against the application requirements.
|
|
| 4 |
EZ1080-09-00-010 — What should be inspected on a stored EZ1080-09-00-010?
Inspect the tip, thread, body, integral cable and connector. Reject crushed cable, contaminated connectors, damaged threads or impact marks until assessed.
|
|
| 5 |
EZ1080-09-00-010 — What must be verified after replacing EZ1080-09-00-010?
Confirm mounting torque and gap, cable routing, gap voltage, sensitivity, monitor scale, alarm state and the machine-specific functional test.
|
