A non-armored 3300 XL 8 mm proximity probe with a 3/8-24 UNF threaded case, zero unthreaded tip length, 5.0 in overall case length, 0.5 m total lead, miniature coaxial ClickLoc connector, standard cable and no agency-approval option.
| Probe 3300 XL 8 mm |
Lead 1.0 m |
Geometry 0.0 in unthreaded / 5.0 in case / 0.5 m lead |
| 330101 | 3300 XL 8 mm probe, 3/8-24 UNF thread, without armor |
| 00 | 0.0 in unthreaded length |
| 50 | 5.0 in overall case length |
| 05 | 0.5 m (1.6 ft) total length |
| 02 | ClickLoc connector, standard cable, no connector protector |
| 00 | Agency approval not required |
| Probe Build and System Performance | |
|---|---|
| Thread | 3/8-24 UNF-2A |
| Linear range | 2.0 mm (80 mils), approximately 0.25 to 2.3 mm gap |
| Scale factor | 7.87 V/mm (200 mV/mil), ±5% |
| Frequency response | 0 to 10 kHz, +0 / -3 dB |
| Minimum target | 15.2 mm (0.6 in) diameter, flat target |
| Target calibration | AISI 4140 steel |
| ◎ | Installation Purpose The long threaded body provides a broad mechanical adjustment range while the 0.5 m lead suits layouts that use a matched extension cable. The probe is one calibrated element of a complete chain; probe lead plus extension cable must match the 5 m or 9 m Proximitor Sensor option. |
| 330101 Probe Detects shaft-to-tip distance |
→ | 330101-00-50-05-02-00 0.5 m non-armored lead |
→ | Extension Cable + 330180 Completes the selected system length |
| Selection Point | 330101-00-50-05-02-00 | Related Choice |
|---|---|---|
| Armor | Without armor | 330102 uses the same UNF thread with armor |
| Connector protector | Not included | Option 01 adds a protector |
| Approval option | 00: not required | 05 selects multiple approvals |
Our large stock of industrial products is ready for delivery. More than 400,000 electronic products cover PLC, HMI, drives, servo and CNC devices, IPC and PG. New and discontinued parts range from individual modules to complete configurations.
Market insight, technology development and customer demand guide strategic purchasing. If an item is temporarily unavailable, our preferred supplier network can support the search. Broad brand coverage helps customers restore production quickly and reduce downtime-related loss.
| Multilingual Support Dedicated customer communication |
Order Tracking Customized relationship management |
Clear Cost Structure No extra handling or hidden charges |
Sales Manager · Configuration Review · Availability · Delivery Coordination
| Email Miya For quotations and configuration checks Send Email → |
WhatsApp Miya For fast order and shipment communication Open WhatsApp → |
| Q | Can 330101-00-50-05-02-00 replace any 3300 XL 8 mm probe? Only after matching thread, case geometry, lead length, connector option, armor, approvals and complete system length. Similar probe tips do not make complete order strings interchangeable. |
| Q | Which Proximitor Sensor works with 330101-00-50-05-02-00? Use a 3300 XL 8 mm Proximitor Sensor whose 5 m or 9 m system option matches the combined probe and extension-cable length. |
| Q | Does 330101-00-50-05-02-00 include hazardous-area approvals? No. The final 00 means agency approval is not required. Use the corresponding 05 approval option when the installation requires the applicable markings. |
| Q | What mounting clearance is needed for 330101-00-50-05-02-00? Allow space for the 5.0 in threaded case, adjustment hardware, cable bend and connector access. Confirm the 3/8-24 UNF port and avoid nearby metal that can affect the probe field. |
| Q | What should be verified after installing 330101-00-50-05-02-00? Check target geometry, connector engagement, total electrical length, static gap voltage, scale, polarity and dynamic channel response before enabling protection logic. |
