A deep-reach 31000 housing assembly with a multiple-approvals 3300 XL 8 mm probe, 1.0 m lead, no standoff adapter, 16.5 in probe penetration, one 3/4-14 NPT conduit fitting, two plugs and a 3/4-14 NPT mounting thread.
| Probe 3300 XL 8 mm |
Lead 1.0 m |
Geometry 0.0 in standoff / 16.5 in penetration |
| 31000 | English proximity probe housing assembly |
| 28 | 3300 XL 8 mm probe with multiple approvals |
| 10 | 1.0 m (39 in) probe cable |
| 00 | No standoff adapter |
| 165 | 16.5 in (419 mm) probe penetration |
| 01 | One 3/4-14 NPT fitting and two plugs |
| 02 | 3/4-14 NPT mounting thread |
| Housing Construction and Installation Limits | |
|---|---|
| Housing body | Conductive glass-reinforced PPS |
| Sleeve | AISI 304 stainless steel |
| Protection | Type 4X and IP66 |
| Temperature | -51°C to +105°C (-60°F to +221°F) |
| C plus D | 16.5 in; additional sleeve support is required |
| Adjustment range | ±0.5 in (±13 mm) |
| Typical weight | 1.2 kg (2.6 lb) |
| ◎ | Installation Purpose The 16.5 in penetration supports deep through-case access while preserving external probe adjustment. Because C plus D exceeds 12 in, a sleeve support near the probe is required to control resonance. The 1.0 m cable permits up to 30 in combined C plus D, and 16.5 in also remains below the 19 in condition for keeping the probe label visible outside the sleeve. |
| 31000 Housing Protects and positions the probe |
→ | 31000-28-10-00-165-01-02 16.5 in supported sleeve reach |
→ | 3300 XL 8 mm Chain Extension cable, sensor and monitor |
| Selection Point | 31000-28-10-00-165-01-02 | Engineering Boundary |
|---|---|---|
| Probe approval | Multiple approvals | Housing use still depends on the complete approved installation |
| Penetration | 16.5 in | Within the 30 in limit for a 1.0 m lead |
| Sleeve support | Required | C plus D is greater than 12 in |
Our large stock of industrial products is ready for delivery. More than 400,000 electronic products cover PLC, HMI, drives, servo and CNC devices, IPC and PG. New and discontinued parts range from individual modules to complete configurations.
Market insight, technology development and customer demand guide strategic purchasing. If an item is temporarily unavailable, our preferred supplier network can support the search. Broad brand coverage helps customers restore production quickly and reduce downtime-related loss.
| Multilingual Support Dedicated customer communication |
Order Tracking Customized relationship management |
Clear Cost Structure No extra handling or hidden charges |
Sales Manager · Configuration Review · Availability · Delivery Coordination
| Email Miya For quotations and configuration checks Send Email → sales@amikon.cn |
WhatsApp Miya For fast order and shipment communication Open WhatsApp → +86 180 2077 6792 |
| Q | Does 31000-28-10-00-165-01-02 need an extra sleeve support? Yes. Its C plus D dimension is 16.5 in, so a support near the probe is required to reduce sleeve resonance. |
| Q | Is the probe included with 31000-28-10-00-165-01-02? Yes. Option 28 includes a 3300 XL 8 mm probe with multiple approvals, and option 10 provides a 1.0 m lead. |
| Q | Can 31000-28-10-00-165-01-02 be used as a pressure vessel boundary? No. The sealing arrangement separates conditions around the probe tip from the housing interior, but the housing is not a pressure vessel. Confirm the machine sealing design separately. |
| Q | What must be checked before ordering 31000-28-10-00-165-01-02? Verify the 3/4-14 NPT mounting port, 16.5 in nominal reach, support location, target clearance, conduit layout, probe approval marking and complete transducer-system length. |
| Q | What commissioning checks apply to 31000-28-10-00-165-01-02? Confirm sleeve support rigidity, retaining-nut torque, conduit sealing, connector engagement, probe gap voltage, system-length match and dynamic response before enabling protection. |
