BENTLY NEVADA 21000-16-10-00-076-03-02 Metal Proximity Probe Housing Assembly
The Bently Nevada 21000 is an all-metal proximity probe housing assembly intended for external mounting of proximity probes. Its assembly design combines a housing body and cover with probe mounting provisions, conduit ports, sealing components and selectable fittings. External access allows probe-gap adjustment or probe replacement without dismantling the machine.
This configured part number identifies a 3300 XL 8 mm probe, a 1.0 m probe cable, no standoff adapter, a 7.6 in penetration, the option-03 cable seal grip arrangement and a 3/4-14 NPT mounting thread. The final fit depends on the machine interface, required approvals and the complete installed transducer system.
|
PROBE OPTION
3300 XL 8 mm
The A16 option specifies the 8 mm probe with connector.
|
CABLE LENGTH
1.0 m / 39 in
Confirm that the configured lead length suits the installed geometry.
|
|
PENETRATION
7.6 in
The D076 option defines the nominal probe penetration dimension.
|
MOUNTING THREAD
3/4-14 NPT
The F02 option identifies the mounting thread.
|
Two assemblies from the same family may differ in probe type, lead length, penetration, standoff adapter, fitting arrangement or thread. Match the complete part number and installed dimensions before confirming a replacement.
| Suffix | Meaning | Configured value |
|---|---|---|
| 21000 | Housing family | Metal probe housing; aluminum body |
| 16 | Probe option | 3300 XL 8 mm probe with connector |
| 10 | Probe cable | 1.0 m (39 in) |
| 00 | Standoff adapter | None |
| 076 | Penetration | 7.6 in |
| 03 | Cable sealing option | Cable seal grip with grommets for specified cable diameter ranges |
| 02 | Mounting thread | 3/4-14 NPT |
The option-03 cable seal grip accommodates specified cable diameters, including 1/8–3/16 in, 1/4–5/16 in and 5/16–3/8 in. Check the actual cable outer diameter and fitting arrangement before installation.
The housing is only one part of a proximity measurement chain. Probe compatibility, extension cable, Proximitor Sensor, monitor input, mechanical geometry and hazardous-area requirements must be considered together.
| Family | Main distinction | Selection focus |
|---|---|---|
| 21000 | Aluminum metal housing | Existing 21000 installations and matching configured geometry |
| 24701 | Stainless-steel housing family | Material requirements and the exact installed interface |
| 164818 | Related metal housing family | Verify its own complete configuration before comparison |
| 31000 / 32000 | PPS housing family with different mounting and environmental design | Alternative installations where an explosion-proof housing is not required |
| 21022 | Dual axial probe housing assembly | Dual-probe shaft axial-position measurements |
Do not assume every standard 21000 configuration is explosion-proof. Confirm the precise housing variant and its approval markings for the installation area. For applications requiring a certified explosion-proof housing, verify the appropriate CA housing configuration and its ordering restrictions.
Our large stock of industrial products is ready for delivery, which is the core of our supply. It contains more than 400,000 electronic products, including PLC, HMI, drives, servo and CNC devices, IPC and PG.
Whether new or out of production, from the smallest module to a complete configuration, we work to locate products across a broad range of generations and technologies.
Market insight, technology development and customer demand guide our purchasing strategy. If an item is not in stock, we can search our preferred supplier network.
We have a wide range of brands and products for various industries, we provide services to tens of thousands of customers around the world. Our goal is to help customers reduce delays to production and keep essential equipment moving.
| Multilingual Support Exclusive multilingual support team |
Order Visibility Customized customer relationship management and order tracking system |
| Transparent Quotation No additional handling or hidden charges; confirmed costs are stated in the quotation |
Global Shipping Options Shipping methods and lead time confirmed with each order |
| Sales Manager | Miya Zheng |
| sales@amikon.cn ↗ | |
| +86 180 2077 6792 ↗ |
Typical delivery: 3–5 days, subject to availability and confirmation. Warranty: 12 months, subject to the quotation and order terms. Shipping options may include FedEx, DHL, UPS, EMS and TNT. Payment terms: T/T, as confirmed in the quotation.
Please contact us within 7 days of receipt if an issue arises. Returned items must remain in their original condition, with the reason for return clearly stated. A return or replacement will be arranged after the returned goods have been received and checked. Return shipping costs are the buyer's responsibility.
Match the complete order code, probe option, 1.0 m cable, no-standoff arrangement, 7.6 in penetration, option-03 cable seal grip, 3/4-14 NPT thread and the required site approvals. Check the machine opening and cable outer diameter rather than relying on the family name alone.
No. Penetration is a defined ordering dimension, not a substitute for the complete assembly dimensions. Verify the mounting interface, machine-case thickness, probe position and available clearance against the installed arrangement.
Option -03 identifies a cable seal grip with grommets for specified cable diameter ranges. Check the actual cable diameter and confirm the complete fitting arrangement required for the installation.
Do not assume so. Hazardous-area suitability depends on the exact housing version, probe approval, associated transducer system and installation conditions. Confirm the required certification before ordering or installing.
Send the complete part number, quantity, destination, required date, a photo of the installed nameplate and mounting point, and details of the existing probe/cable/monitor chain if available. This helps check the correct configuration instead of a similar-looking variant.
