The Bently Nevada 31000/32000 proximity probe housing assemblies are intended for mounting proximity probes through a machine case. They are typically used for radial vibration or Keyphasor measurements. The housing provides external access to the probe and extension cable so that gap adjustment or probe replacement can be performed without dismantling the machine.
This configuration specifies a 3300 XL NSv probe with connector protector and selectable hazardous-area approvals, a 0.5 m cable, a 1.5 in standoff adapter, a 3.0 in penetration, option-02 fittings and a 3/4-14 NPT mounting thread. The complete transducer system, actual machine dimensions and approval conditions must be checked before installation.
|
01 / PROBE
3300 XL NSv
Connector protector included in the selected probe option.
|
02 / CABLE & STANDOFF
0.5 m + 1.5 in
The specified lead and standoff arrangement must fit the installed machine geometry.
|
|
03 / PENETRATION
3.0 in
The D030 option specifies a 3.0 in penetration dimension.
|
04 / HOUSING MATERIAL
PPS + metal components
The housing body uses glass-reinforced PPS; other components use corrosion-resistant metal materials as specified for the assembly.
|
The nominal combined standoff and penetration dimensions are 1.5 in + 3.0 in = 4.5 in. This value alone does not prove fit. Verify probe-lead-length limits, cable-label visibility, the actual mounting interface and the clearance available at the machine.
| Suffix | Meaning | Configured value |
|---|---|---|
| 31000 | Housing family | PPS proximity probe housing assembly |
| 32 | Probe option | 3300 XL NSv probe with connector protector and selectable hazardous-area approvals |
| 05 | Probe cable length | 0.5 m (20 in) |
| 15 | Standoff adapter | 1.5 in (38 mm) |
| 030 | Probe penetration | 3.0 in |
| 02 | Fittings option | Two 3/4-14 NPT fittings, including one plug, per the specified option |
| 02 | Mounting thread | 3/4-14 NPT |
The 31000/32000 housing family is designed for external probe access, commonly for radial vibration or Keyphasor measurements. For radial vibration, the machine casing should be affixed to the bearing to support accurate relative vibration measurement. For dual-probe shaft axial-position measurement, the 21022 housing family is the specific option to review.
| Family | Main distinction | Selection focus |
|---|---|---|
| 31000 | PPS housing assembly with configurable probe and fitting options | Configured external probe mounting and matching installed assemblies |
| 32000 | Related PPS housing family with its own order options | Confirm the original family, mounting dimensions and full suffix |
| 21000 | Aluminum metal housing | Metal housing preference and matching the existing 21000 configuration |
| 24701 | Stainless-steel housing family | Material-specific needs and matching the installed interface |
| 164818 | Related metal housing family | Verify its own complete part number and application |
| 21022 | Dual axial probe housing assembly | Dual-probe shaft axial-position measurements |
The 31000/32000 housing is intended to provide mechanical and environmental protection and is not an explosion-proof housing. Type 4X / IP66 ratings do not mean pressure-tight or explosion-proof. Intrinsically safe use requires an approved transducer system, appropriate I.S. barriers and compliance with the installation requirements.
Our large stock of industrial products is ready for delivery, which is the core of our supply. It contains more than 400,000 electronic products, including PLC, HMI, drives, servo and CNC devices, IPC and PG.
Whether new or out of production, from the smallest module to a complete configuration, we work to locate products from many generations of industrial technology.
Market insight, technology development and customer demand guide our purchasing strategy. If an item is not in stock, we can search our preferred supplier network.
We have a wide range of brands and products for various industries, we provide services to tens of thousands of customers around the world. Our goal is to help customers reduce production delays and keep equipment running.
| Multilingual Support Exclusive multilingual support team |
Order Tracking Customized customer relationship management and order tracking system |
| Clear Quotation No additional handling or hidden charges; confirmed costs are stated in the quotation |
Global Delivery Shipping methods and delivery timing confirmed for each order |
| Sales Manager | Miya Zheng |
| sales@amikon.cn ↗ | |
| +86 180 2077 6792 ↗ |
Typical delivery: 3–5 days, subject to availability and confirmation. Warranty: 12 months, subject to the quotation and order terms. Shipping options may include FedEx, DHL, UPS, EMS and TNT. Payment terms: T/T, as confirmed in the quotation.
Please contact us within 7 days of receipt if an issue arises. Returned items must remain in their original condition, with the reason for return clearly stated. A return or replacement will be arranged after the returned goods have been received and checked. Return shipping costs are the buyer's responsibility.
Confirm the 3300 XL NSv probe option, 0.5 m cable, 1.5 in standoff, 3.0 in penetration, option-02 fittings, 3/4-14 NPT mounting thread, required approvals and available machine clearance. Compare the full suffix and actual installation dimensions.
No. It is the nominal sum of the selected standoff and penetration dimensions. The complete probe lead arrangement, cable label position, machine-case geometry and clearance still need to be checked.
The housing itself is not explosion-proof. For hazardous-area use, verify the approved probe and transducer system, required intrinsic-safety barriers and the applicable site installation requirements. Where an explosion-proof housing is mandatory, check the appropriate approved housing family instead.
Compare the installed housing family, material, mounting thread, penetration, fitting arrangement and hazardous-area requirements. The 31000/32000 family uses a PPS housing body, while 21000 is an aluminum housing. They are not automatic drop-in replacements for one another.
Provide the full part number, quantity, destination, required date, machine type, photos of the existing housing and mounting point, plus the current probe/cable arrangement. Include the monitor or transducer system and site approval requirements when known.
