BENTLY NEVADA
146054-36-05-01-05
3300 XL Ceramic Capped Proximity Probe
A ceramic-capped proximity probe designed for demanding machinery monitoring applications where the sensing end may encounter aggressive chemical or high-pressure conditions.
EDDY-CURRENT SENSING MACHINERY MONITORING
|
FAST INQUIRY
Need This Part?
Contact our sales manager directly for availability and quotation.
EMAILsales@amikon.cn PHONE / WHATSAPP+86 180 2077 6792
Sales Manager: Miya Zheng
|
|
01
Ceramic-Capped Design
The ceramic cap provides protection at the sensing end for applications involving aggressive chemical environments.
|
02
Eddy-Current Proximity
Designed as part of a proximity measurement system for monitoring machinery motion and shaft-related behavior.
|
03
Harsh-Environment Focus
Suitable for applications where the front portion of the probe assembly may be exposed to corrosive gases or liquids.
|
|
APPLICATION VIEW
Designed for Critical Rotating Equipment
Proximity measurement is widely used within machinery condition monitoring to observe critical machine behavior. Bently Nevada monitoring solutions support applications across rotating equipment and other critical assets.
When monitoring quality becomes critical
A degraded probe, damaged sensing surface, incorrect installation, or unstable measurement chain can compromise the quality of machinery condition data and increase diagnostic uncertainty.
|
SERVICE READY
Practical Supply Support
|
|
01. What type of sensing technology is used?
It belongs to the eddy-current proximity measurement family used for machinery monitoring applications.
|
|
02. Why is the ceramic cap important?
The ceramic sensing-end construction is intended for applications where the front of the probe can encounter aggressive chemical conditions or elevated pressure.
|
|
03. Can the probe operate as a standalone monitoring device?
The probe forms part of a complete proximity transducer system and is used with the appropriate Proximitor sensor and extension cable.
|
|
04. Where is this type of probe especially useful?
It is particularly useful when the sensing end requires additional protection from corrosive gases or liquids in demanding machinery environments.
|
|
05. What should be checked when replacing the probe?
Confirm the complete part-number configuration, mechanical installation, probe gap, compatible Proximitor sensor and associated extension cable before commissioning.
|
|
