POWERFLEX 7000 / HMI INTERFACE
80190-780-01-R

HMI Interface Board for PowerFlex 7000 ForGe Drives
The 80190-780-01-R is the HMI Interface Board used with PowerFlex 7000 ForGe drives. The assembly forms part of the drive control platform and connects to the Drive Processor Module (DPM). The board assembly incorporates the PFNI PowerFlex Network Interface Board and a processor-module socket for the NetBurner module.
PART NUMBER
80190-780-01-R
Platform
PowerFlex 7000 ForGe
Assembly
HMI Interface Board
Product Architecture & Role
The 80190-780-01-R HMI Interface Board is integrated into the PowerFlex 7000 ForGe control platform through the DPM. The assembly consists of two circuit boards: the PFNI base board and the processor-module section. The PFNI board provides the interface structure for the NetBurner processor module and incorporates the configurable port functions used for diagnostic and data-access purposes.

Key Features
Drive Integration Connects to the DPM and becomes part of the PowerFlex 7000 drive control platform.
PFNI Base Board Uses the PowerFlex Network Interface Board as the base section of the HMI assembly.
Processor Interface Provides the socket through which the NetBurner processor module connects to the PFNI board.
Diagnostic Access J3 can provide the diagnostic port as a standard USART connection or through USB depending on the port-switch configuration.
DIM Support The PFNI includes an internal DIM and provides a socket for an external DIM.

Technical Specifications
Part Number 80190-780-01-R
Board Type HMI Interface Board
Base Board PFNI — PowerFlex Network Interface Board
Processor Interface NetBurner processor-module socket
Drive Connection Drive Processor Module (DPM)
Diagnostic Port J3; standard USART / USB availability according to SW2 port configuration
Port Switch SW2 Switch 1; factory/default position is OFF
DIM Arrangement Internal DIM plus socket for external DIM
Applicable Drive Family PowerFlex 7000 ForGe
SW2 Port Configuration
The first SW2 switch controls which port is assigned to the USB connection. With the switch OFF, Port 1 is on USB; with the switch ON, Port 0 is on USB. Port 0 is also available through J3 as a standard USART diagnostic connection. The documented default position is OFF.
SW2-1 USB Assignment
ON Port 0 is on USB
OFF / Default Port 1 is on USB
PowerFlex 7000 ForGe Series Position
The 80190-780-01-R belongs to the HMI interface architecture used with PowerFlex 7000 ForGe drives. Its role is different from the main Drive Processor Module: the HMI board provides the interface layer that connects into the DPM and incorporates the PFNI network-interface base board and processor-module connection.
80190-780-01-R HMI Interface Board assembly for PowerFlex 7000 ForGe drives.
PFNI PowerFlex Network Interface Board forming the base section of the HMI assembly.
DPM Drive Processor Module; the HMI Interface Board connects into the DPM as part of the drive control platform.
NetBurner Module Processor module connected through the socket provided on the PFNI board.

Application & Replacement Considerations
The 80190-780-01-R is relevant when maintaining or retrofitting a PowerFlex 7000 ForGe drive equipped with the newer HMI Interface Board architecture. Rockwell Automation's firmware procedure specifically covers retrofitting an existing PowerFlex 7000 ForGe drive with this HMI board and updating the drive firmware together with HMI Interface Board firmware.
Board Replacement
Useful when an existing HMI Interface Board requires replacement and the drive configuration must be retained.
Firmware Work
Applicable to firmware-update work involving the PowerFlex 7000 ForGe drive and HMI Interface Board.
Communication Diagnosis
During update or communication problems, the documented procedure includes checking the Ethernet connection and, for a Comm Error during download, resetting the HMI Interface Board before retrying.
AMIKON INDUSTRIAL AUTOMATION SUPPLY
Need 80190-780-01-R?
Send your exact part number and application details to our sales team. For PowerFlex 7000 HMI board replacement requirements, providing the existing drive/system context helps us check the requested configuration more precisely.
Sales Manager: Miya zheng
Delivery: 3–5 days Warranty: 12 months Condition: Brand New Payment: T/T
Delivery Way: E-packing / FedEx / EMS / TNT / DHL / UPS
Quotation Checklist
To make the quotation and compatibility check more efficient, please include:
Part Number Quantity Destination Required Date Machine / System
80190-780-01-R Buyer FAQ
01. Is 80190-780-01-R the correct replacement when a PowerFlex 7000 ForGe HMI Interface Board needs to be renewed?
The part number is specifically documented as the HMI Interface Board used with PowerFlex 7000 ForGe drives. Before ordering, the existing board part number and drive configuration should be checked against the actual installation.
02. Can 80190-780-01-R be involved in a PowerFlex 7000 ForGe retrofit rather than only a direct board replacement?
Yes. Rockwell Automation's update procedure explicitly covers retrofitting an existing PowerFlex 7000 ForGe drive with the new HMI Interface Board. The procedure also addresses updating the drive firmware and HMI Interface Board firmware together.
03. What should be checked when 80190-780-01-R is being replaced on an operating PowerFlex 7000 system?
The replacement should be treated as part of the complete HMI/control architecture rather than as an isolated circuit board. The existing SD card is specifically required to be moved to the new HMI Interface Board during replacement, and the drive/HMI firmware relationship should also be considered.
04. Why does 80190-780-01-R matter when an HMI firmware update or communication fault occurs?
The HMI Interface Board is directly involved in the PowerFlex 7000 firmware-update path. The documented update process uses Ethernet communication, and a Comm Error during the download procedure calls for resetting the HMI Interface Board and retrying the operation.
05. How can I reduce the risk of ordering the wrong 80190-780-01-R board for an existing drive?
Provide the complete 80190-780-01-R part number together with the PowerFlex 7000 drive context, required quantity, destination and required date. For a replacement project, confirming the existing HMI board arrangement and drive configuration before shipment is particularly useful.
