80190-540-02-R

Temperature Feedback Board
The Allen-Bradley 80190-540-02-R is a packaged customer Temperature Feedback Board used within the PowerFlex 7000 medium-voltage AC drive platform. The board belongs to the temperature-feedback architecture used to monitor thermal conditions within the drive power section and support the drive's protection and diagnostic functions.
PART NUMBER
80190-540-02-R
Product Family
PowerFlex 7000
Board Function
Temperature Feedback
Configuration
Conformal-Coated TFB
Product Overview
The 80190-540-02-R is associated with the Temperature Feedback Board function in PowerFlex 7000 medium-voltage AC drives. Within the drive architecture, temperature feedback is used to monitor thermal conditions associated with power components and to support protective decisions. The PowerFlex 7000 control system uses temperature-feedback channels to determine the declared location of temperature feedback boards and to monitor temperature-related conditions.
The board is particularly relevant to maintenance of legacy PowerFlex 7000 installations where the temperature-feedback circuit must remain available for normal drive protection, diagnostics and controlled operation.

Key Features
Temperature Feedback Provides the board-level temperature-feedback function used by the PowerFlex 7000 drive control architecture.
PowerFlex 7000 Integration Designed for the temperature-feedback architecture of the PowerFlex 7000 medium-voltage AC drive family.
Conformal-Coated Configuration The 80190-540-02-R is associated with the packaged customer TFB configuration with conformal coating.
Thermal Protection Role Temperature-feedback signals are incorporated into the PowerFlex 7000 protection and diagnostic structure.
Legacy Drive Support Useful for maintaining installed PowerFlex 7000 systems where the original temperature-feedback hardware requires replacement.

Technical Specifications
Manufacturer Allen-Bradley / Rockwell Automation
Part Number 80190-540-02-R
Product Type Temperature Feedback Board
Drive Family PowerFlex 7000 Medium Voltage AC Drives
Feedback Function Temperature monitoring within the drive power architecture
Board Configuration Packaged customer TFB board with conformal coating
Drive Control Function Temperature feedback used by drive monitoring, protection and diagnostics
Lifecycle Relationship Direct replacement for discontinued 8019064022R
PowerFlex 7000 Temperature-Feedback Series
The PowerFlex 7000 platform uses temperature-feedback boards as part of its thermal monitoring and protection architecture. Depending on the drive configuration, temperature sensors are associated with heatsinks in the rectifier and inverter sections, while the optical interface boards receive temperature-feedback signals for the applicable configuration.
80190-540-02-R Packaged customer Temperature Feedback Board configuration with conformal coating.
80190-640-02-R Another PowerFlex 7000 temperature-feedback board part number. It should not be treated as an automatic substitute for 80190-540-02-R without configuration verification.
Temperature Feedback Architecture The drive monitors temperature-feedback channels associated with defined drive locations such as rectifier heatsinks, inverter heatsinks and other configured positions.
TFB Generations Later generations of the PowerFlex 7000 temperature-feedback architecture can also provide gate-power-supply monitoring for SGCT-based drives.

Application & Fault-Recovery Scenarios
The 80190-540-02-R is relevant to PowerFlex 7000 maintenance where temperature feedback must be restored or preserved. A temperature-feedback problem can affect drive diagnostics and protective behavior, so the board should be evaluated together with the associated sensors, optical connections and drive configuration.
Temperature Feedback Loss
If the drive reports loss of temperature feedback, inspect sensor seating, the relevant feedback path, fiber-optic connections and TFB power before deciding that the board itself has failed.
TFB Fiber-Optic Fault
PowerFlex 7000 diagnostics include faults associated with loss of the fiber-optic signal from the specified temperature-feedback board. Damaged or loose fiber connections should be checked before board replacement.
Thermal Protection
Temperature feedback supports the drive's thermal protection strategy. Sensor condition, feedback routing and board condition should therefore be considered together during troubleshooting.
Why Exact Part-Number Matching Matters
PowerFlex 7000 contains multiple feedback-board variants and different drive configurations use different temperature-feedback arrangements. For a replacement order, the complete 80190-540-02-R designation should be checked against the installed board and the drive configuration rather than selecting a board only by general temperature-feedback function.
AMIKON INDUSTRIAL AUTOMATION SUPPLY
Need 80190-540-02-R?
Send the complete part number together with the installed drive or system details. For a PowerFlex 7000 replacement requirement, the existing board marking and drive configuration can help reduce the risk of selecting an incorrect feedback-board variant.
Sales Manager: Miya zheng
Delivery: 3–5 days Warranty: 12 months Condition: Brand New Payment: T/T
Delivery Way: E-packing / FedEx / EMS / TNT / DHL / UPS
What to Include in Your RFQ
For a faster quotation and compatibility review, please provide the following five items:
Part Number Quantity Destination Required Date Machine / System
80190-540-02-R Buyer FAQ
01. Is 80190-540-02-R the correct board when the installed PowerFlex 7000 system reports a temperature-feedback problem?
It can be relevant, but the fault alone is not sufficient to confirm board failure. PowerFlex 7000 troubleshooting also considers the temperature sensor, fiber-optic path, connections and board power. The installed board marking and drive configuration should be checked before replacement.
02. Why should I verify the exact 80190-540-02-R suffix instead of ordering another PowerFlex 7000 temperature-feedback board?
PowerFlex 7000 uses multiple temperature-feedback board configurations. A board that performs the same general function should not automatically be assumed to have identical hardware or configuration requirements. The complete part number should therefore be matched to the installed assembly.
03. What makes 80190-540-02-R particularly relevant to maintenance of an older PowerFlex 7000 installation?
The part belongs to the established PowerFlex 7000 temperature-feedback architecture and is the direct replacement associated with the discontinued 8019064022R. For installed systems, retaining the correct feedback hardware can be important when maintaining the original drive protection and diagnostic arrangement.
04. What should be investigated before replacing an 80190-540-02-R after a TFB fiber-optic fault?
Inspect the relevant fiber-optic cable and connector seating first, then check the temperature sensor and TFB power condition. PowerFlex 7000 troubleshooting procedures associate TFB feedback faults with loss of the fiber-optic signal, so replacing the board without checking the communication path can lead to unnecessary replacement.
05. Can 80190-540-02-R be ordered solely by matching the PowerFlex 7000 family name?
No. The PowerFlex 7000 family contains different drive configurations and feedback-board variants. For a procurement decision, provide the exact board part number, the drive/system identification and, when possible, the existing board marking so the requested configuration can be checked before shipment.
