ALLEN-BRADLEY / POWERFLEX 7000
80190-478-51
Drive Control Board for PowerFlex 7000 Medium-Voltage Drive Systems
The 80190-478-51 designation is associated with the PowerFlex 7000 drive-control architecture and is cross-referenced with 80190-480-01-R in industrial spare-part listings. The assembly is used as a control-board component within PowerFlex 7000 medium-voltage AC drive systems, where dependable drive control and replacement continuity are important for maintaining motor-driven process equipment.
|
|
|
480 VAC
Drive Rating
|
15 A
Current Rating
|
7.2 kW
Power Rating
|
4
Motor Support
|
16 + 16
Digital I/O
|
|
Control Architecture
The 80190-478-51 / 80190-480-01-R assembly belongs to the PowerFlex 7000 drive-control environment. It functions as a drive control board rather than as a standalone motor starter, and its role is tied to the control and coordination of the associated medium-voltage drive system.
For replacement work, the complete drive configuration, board designation, revision and existing cabinet arrangement should be checked before purchase. A board that looks similar is not automatically interchangeable.
|
Key Characteristics
|
| Parameter | Specification |
| Primary Part Number | 80190-478-51 |
| Associated Assembly | 80190-480-01-R |
| Series | PowerFlex 7000 |
| Component Category | Drive Control Board / Customer Drive Control Board Assembly |
| Voltage Configuration | 480 VAC |
| Current Rating | 15 A |
| Power Rating | 7.2 kW |
| Motor Support | Up to 4 motors, configuration dependent |
| Digital Inputs | 16 × 24 V DC |
| Digital Outputs | 16 digital outputs |
| I/O Isolation | 500 V DC channel-to-channel |
| Operating Temperature | 0 to +50 °C; derating above 40 °C applies to the stated configuration |
| Storage Temperature | −20 to +70 °C for the stated configuration |
|
POWERFLEX PLATFORM
7000 Series
|
PowerFlex 7000 is a medium-voltage AC drive platform intended for large industrial motor applications. The platform is used where controlled motor speed, process continuity and drive-level protection are important. The 80190-478-51 / 80190-480-01-R control-board configuration belongs to this drive-control environment.
|
|
Drive Control
Control-board architecture for the associated PowerFlex 7000 drive system.
|
Medium Voltage
Designed for industrial medium-voltage drive applications rather than low-voltage standalone drives.
|
System Continuity
Useful as a replacement consideration when an installed PowerFlex 7000 system requires control-board maintenance.
|
|
Where the Board Fits
The PowerFlex 7000 platform is used in demanding industrial motor-control environments. A control-board replacement can become relevant in production systems where the drive cabinet remains serviceable but the control electronics require replacement because of age, electrical stress, component failure or maintenance findings.
Typical sectors associated with medium-voltage drive applications include heavy manufacturing, process industries, utilities, water systems, mining and other facilities using large motor-driven equipment.
|
|
|
BEFORE ORDERING
Match the installed configuration
|
|
|
DIRECT SALES SUPPORT
Need 80190-478-51?
Send the exact part number and your machine details so our sales team can verify the requested configuration and quotation requirements.
|
|
||||
|
DELIVERY
3–5 Days
|
WARRANTY
12 Months
|
PACKAGING
Brand New
|
PAYMENT
T/T
|
SHIPPING
E-packing / FedEx / EMS / TNT / DHL / UPS
|
|
01. How can I confirm whether 80190-478-51 is the correct replacement for my installed drive?
Match the part number, associated assembly designation, PowerFlex 7000 configuration and board revision against the installed unit. The 80190-478-51 designation is associated with 80190-480-01-R, but final interchangeability should be confirmed against the actual drive configuration before installation.
|
02. What configuration details should I provide when purchasing 80190-478-51?
Provide the exact part number, quantity, destination, required date and machine/system information. For replacement work, the drive model, cabinet configuration and existing board identification are also useful for checking compatibility.
|
|
03. Why is 80190-478-51 relevant when maintaining an older PowerFlex 7000 installation?
Control electronics can become a maintenance constraint as an installed drive ages. Keeping the correct control-board assembly available can reduce the time spent waiting for a suitable replacement when an existing drive requires board-level maintenance.
|
04. What should be checked if an 80190-478-51 replacement does not behave like the original board?
Check the exact board designation, revision, drive configuration, wiring, connectors and associated control components. A replacement should not be treated as interchangeable solely because the board dimensions or part-number family appear similar.
|
|
05. Can I purchase 80190-478-51 as a maintenance spare before a PowerFlex 7000 failure occurs?
Yes. It can be considered as a maintenance-stock item for an installed PowerFlex 7000 system, particularly where control-board downtime would affect production continuity. Before stocking, verify the exact part designation and installed drive configuration so the spare matches the intended application.
|
|
|
