POWERFLEX 7000 / XIO CONTROL ARCHITECTURE
80190-300-01-R
XIO External Input / Output Board
The 80190-300-01-R is the 120–240 V AC XIO board associated with the PowerFlex 7000 medium-voltage AC drive platform. Within the drive control architecture, XIO functions provide external input/output handling for configured drive functions, including external fault and warning interfaces.
|
PART IDENTIFICATION
80190-300-01-R
|
|
01
|
Product Details
A control-layer component for PowerFlex 7000 systems
The 80190-300-01-R belongs to the XIO group used with PowerFlex 7000 medium-voltage AC drives. Its specified role is external input/output handling at 120–240 V AC. The XIO architecture allows configured external signals to participate in drive monitoring, protection and control functions.
|
| Part Number | 80190-300-01-R |
| XIO Type | External Input / Output board |
| Voltage Class | 120–240 V AC |
| Drive Platform | PowerFlex 7000 Medium Voltage AC Drives |
| Primary Role | External input/output interface within the drive control architecture |
| Related XIO Variant | 80190-300-02-R — 12–24 V AC XIO board |
| Related Control Boards | 80190-560-01-R, 80190-560-02-R and 80190-580-01-R |
|
02
|
PowerFlex 7000 Control Board Family
The 80190-300-01-R sits within a broader PowerFlex 7000 control-board architecture. Selection between related boards is function-specific rather than interchangeable by appearance alone. The XIO voltage class and assigned function should be matched to the existing drive configuration.
Replacement Perspective
The closest same-family comparison is 80190-300-02-R because both are XIO boards. Their voltage classes differ, however, so they should not be treated as automatic substitutes. The 80190-560 and 80190-580 boards serve different control functions and should be considered only when the drive configuration specifically calls for those board types.
|
|
03
|
Application & Fault Scenarios
Replacement Checkpoint
When a PowerFlex 7000 system reports an XIO-related fault, replacing the board should not be the first assumption. Verify the XIO assignment, external signal path, board connections and XIO power condition. If the existing board is being replaced, confirm that the replacement has the same part number and voltage class required by the drive.
|
|
AMIKON AUTOMATION PARTS
Confirm the exact part
before replacement. For quotation, please provide the five key details below so our team can check the requested component accurately.
|
|
| Delivery 3–5 Days |
Warranty 12 Months |
Condition Brand New |
Payment T/T |
Packaging New |
|
04
|
Buyer-Focused FAQ
Why should I verify the voltage class before ordering 80190-300-01-R?
Because 80190-300-01-R is the 120–240 V AC XIO variant, while the closely related 80190-300-02-R is specified for 12–24 V AC. The two part numbers therefore should not be treated as interchangeable solely because both belong to the XIO family.
When does 80190-300-01-R become a relevant replacement candidate in a PowerFlex 7000?
It is relevant when the existing configuration calls for the 120–240 V AC XIO board and the replacement must preserve the same XIO function. If the drive requires another XIO voltage class or a different control-board function, the matching part number must be selected instead.
How can 80190-300-01-R relate to an “External 1–16” drive fault?
PowerFlex 7000 uses configured XIO inputs for additional external fault or warning functions. When an External 1–16 message appears, the associated external circuit and XIO input should be investigated rather than assuming that the board itself has failed.
What should I check if 80190-300-01-R is associated with an XIO Card Loss condition?
Check the XIO communication path, connections and board status before replacement. The PowerFlex 7000 troubleshooting sequence specifically directs attention to the communication link and XIO-related connections when an XIO card is reported lost.
Is 80190-300-01-R a suitable substitute for 80190-560-01-R or 80190-580-01-R?
They serve different roles. 80190-300-01-R is an XIO board, 80190-560-01-R is an analog control board for an 18-pulse drive configuration, and 80190-580-01-R is a drive processor board. A replacement should therefore be matched to the board function required by the specific PowerFlex 7000 configuration.
|
|
