Allen Bradley 80173-109-01-3 Board Module

Allen Bradley 80173-109-01-3  Board Module

Parameters

&Device type: Gate-Commutated Turn-off (GCT) thyristor stack for medium-voltage drives

&Repetitive peak voltages: VDRM / VRRM 6 500 V; non-rep. 6 500 V

&RMS on-state current: 800 A; average 520 A; surge 4.8 kA (10 ms)

&Controllable turn-off current: 330 A repetitive

&di/dt capability: 1 000 A µs⁻¹ on-state & reverse recovery

&Gate ratings: VFGM 10 V, VRGM 21 V; IFGM 500 A, IRGM 800 A; PFGM 5 kW / PRGM 17 kW peak

&On-state voltage: ≤ 5.5 V @ 800 A; thermal limit –20 °C … +60 °C (op)

&Mechanical: 200 × 100 × 50 mm, 1.5 kg, DIN-rail or chassis mount, RS-232/485 interface on driver board

Applications

&Medium-voltage VFDs (2.3–4.16 kV) for ID/FD fans and compressors—gives fast, low-loss switching up to multi-MW levels.

&High-power UPS & grid-tie inverters—GCT structure handles 6 kV DC link and 1 kA µs⁻¹ di/dt without snubbers.

&Steel-mill conveyor or crane drives—150 % overload for 1 min and gate turn-off provide safe, quick stops on heavy inertia loads.
