Allen Bradley 80173-110-02-3 Overload Relay

Allen Bradley 80173-110-02-3 Overload Relay

Parameters

&Module type: single-phase thyristor (SCR) power board for Allen-Bradley PowerFlex 7000 medium-voltage drives

&Input voltage: 100 – 480 V AC (50/60 Hz) / 24 V DC logic supply

&Output current: 200 A continuous, 400 A peak (1 s) per SCR leg

&Gate trigger: 3 – 12 V DC, 50 – 150 mA (pulse)

&Switching loss: < 65 W per device at 400 A, 60 Hz

&Operating temp: –40 °C … +70 °C; storage –55 °C … +125 °C

&Protection: RC-snubber, MOV, 2 kV isolation, IP20 touch-safe cover

&Size / weight: 120 × 100 × 60 mm, 0.5 kg; DIN-rail or chassis mount

Applications

&PowerFlex 7000 MV drive phase-leg—replaces worn SCR pairs to restore 2.3–4.16 kV motor control without changing the whole stack.

&MV soft-starter cubicles—gives smooth 200–400 A ramp-up for large pumps or fans while limiting in-rush to < 3 × FLA.

&Steel-mill conveyor sections—rugged –40 °C … +70 °C rating lets the same board work on roller tables, coiler drives and crane long-travel.
