Allen Bradley 25B-D4P0N104 PowerFlex 525 Adjustable Frequency AC Drive

Allen Bradley 25B-D4P0N104
Allen Bradley 25B-D4P0N104
Allen Bradley 25B-D4P0N104

Allen Bradley 25B-D4P0N104 PowerFlex 525 Adjustable Frequency AC Drive

Calculate shipping
Quotation Request
ALLEN-BRADLEY
25B-D4P0N104

PowerFlex 525
INPUT
380–480V AC
3-Phase
OUTPUT
4.0 A
1.5 kW / 2 Hp
FRAME
Frame A
IP20 / NEMA Open
SALES MANAGER
Miya Zheng
EMAIL
sales@amikon.cn
PHONE / WHATSAPP
86-18020776792

Allen-Bradley 25B-D4P0N104 Overview Specifications Applications FAQ Contact
POWERFLEX 525 AC DRIVE
25B-D4P0N104
1.5 kW • 2 Hp • 4.0 A
A PowerFlex 525 adjustable frequency AC drive designed for three-phase 380–480V AC applications, with embedded EtherNet/IP, integrated safety capabilities and a compact Frame A construction.
380–480V AC   3-Phase   IP20 / Open Type
POWERFLEX 525
525

Compact AC Drive
Frame A
POWER
1.5 kW
OUTPUT
4.0 A
INPUT
380–480V AC
FRAME
A
01 / PRODUCT OVERVIEW
Compact Drive Architecture
Built for practical motor control
The 25B-D4P0N104 belongs to the PowerFlex 525 family and is rated for 1.5 kW (2 Hp) applications with a 4.0 A output rating. Its three-phase input is rated at 380–480V AC, while the drive provides a 0–460V three-phase output range.

KEY CONFIGURATION
Embedded EtherNet/IP
Integrated Safety
Brake IGBT Included
Integral Keypad + Potentiometer
LED Display
02 / TECHNICAL SPECIFICATIONS
Core Ratings & Configuration
Parameter 25B-D4P0N104
Product Family PowerFlex 525
Drive Type Adjustable Frequency AC Drive
Input Voltage 380–480V AC, 3-Phase
Input Voltage Tolerance −15% / +10%
Output Voltage 0–460V, 3-Phase
Normal-Duty Power 2 Hp / 1.5 kW
Heavy-Duty Power 2 Hp / 1.5 kW
Output Current 4.0 A
Frequency Rating 50–60 Hz
Frame A
Enclosure Rating IP20 / NEMA Open Type
Filter No Filter
Brake IGBT Included
Power Factor 0.98
Network Embedded EtherNet/IP
User Interface Integral Keypad with Potentiometer and LED Display
03 / FUNCTIONAL DESIGN
Where the Configuration Matters
EtherNet/IP
Embedded EtherNet/IP supports integration into compatible industrial control architectures without requiring a separate communication option for the basic network capability.

Integrated Safety
The PowerFlex 525 platform incorporates safety functionality as part of its drive architecture, making the configuration suitable for machine designs where drive-level safety capability is required.

Local Interface
An integral keypad, potentiometer and LED display provide a local interface for drive operation and parameter access.
04 / APPLICATION CONTEXT
When the Drive Becomes Critical
Typical System Position
The 25B-D4P0N104 is normally used as the variable-speed drive between a three-phase AC supply and a motor in a machine or industrial control system. Its PowerFlex 525 architecture makes it particularly relevant where a compact 1.5 kW drive, EtherNet/IP connectivity and integrated safety capability are required.

Why Engineers Search This Exact Part Number
When a drive in an operating machine develops a fault, loses normal motor control, or cannot return to service, the exact catalog number becomes important because voltage class, current rating, power rating, frame and configuration all need to match the installed unit. Replacing it with a different rating can introduce additional engineering and commissioning work.

Typical Downtime Exposure
A failed variable-frequency drive can stop the motor it controls and, depending on the machine architecture, interrupt a complete production sequence. For continuously operating equipment, the practical cost is often associated with lost machine availability, delayed production and the time required for replacement and recommissioning.

Replacement Matching
For replacement purchasing, verify the catalog number against the installed drive and confirm the required voltage, output current, motor power, frame and network arrangement before placing an order. This helps avoid receiving a physically similar drive with a different electrical configuration.
05 / PURCHASING SUPPORT
Make the Quote Easier to Match
01
Part Number
02
Quantity
03
Destination
04
Required Date
05
Machine / System
For quotation, please provide Part Number, Quantity, Destination, Required Date, and Machine/System. These details help match the requested unit to the application and delivery requirement.
06 / ORDER TERMS
Delivery & Commercial Terms
DELIVERY
3–5 Days

WARRANTY
12 Months

PACKAGING
Brand New

PAYMENT
T/T
Delivery way
E-packing / FedEx / EMS / TNT / DHL / UPS
07 / PURCHASING FAQ
Five Questions Before Replacement
1. Why does the exact 25B-D4P0N104 catalog number matter when replacing a failed PowerFlex 525 drive?
Because this configuration combines a specific voltage class, 4.0 A output, 1.5 kW / 2 Hp rating, Frame A construction, no filter and embedded EtherNet/IP with integrated safety. Matching the complete configuration reduces the risk of an electrical or system-level mismatch.

2. What should be checked if a 25B-D4P0N104 is being purchased for an urgent machine restart?
Confirm the installed catalog number, quantity required, destination, required date and the machine or system where the drive will operate. For a replacement situation, these details are more useful than simply matching the nominal horsepower.

3. How does the 380–480V class affect the suitability of 25B-D4P0N104?
The drive is designed for a 380–480V AC three-phase input with a −15% / +10% input tolerance. A replacement should therefore be evaluated against the actual supply arrangement rather than selecting a drive solely from the 1.5 kW motor rating.

4. When is the embedded EtherNet/IP capability particularly valuable for a 25B-D4P0N104 replacement?
It is particularly relevant when the existing drive communicates through an EtherNet/IP-based control architecture. Retaining the same communication capability can simplify replacement planning and help preserve the intended drive-to-control-system arrangement.

5. What makes the 25B-D4P0N104 worth matching precisely when downtime is already affecting production?
The drive is part of the motor-control chain, so an incorrect replacement can extend commissioning time even when the power rating appears similar. A precise catalog-number match can reduce unnecessary changes to the existing machine configuration and support a faster return to operation.
