Keep Controller RAM Alive Through Power LossSB522V1 3BSC760015R1
The SB522V1 is a rechargeable nickel-metal hydride battery unit for ABB AC 400 systems. It supplies backup current for RAM and is charged and discharged through the associated battery-charger arrangement. |
12 V Rechargeable battery
4 Ah Rated capacity
3.4 A Internal fuse
|
| Product identity | SB522V1 battery unit for AC 400 systems |
| ABB product ID | 3BSC760015R1 |
| Battery chemistry | Nickel-metal hydride, rechargeable |
| Nominal voltage | 12 V |
| Rated capacity | 4 Ah |
| Internal protection | 3.4 A fuse |
| Primary duty | Backup current supply for controller RAM |
| Charging relationship | Charging and discharging through the battery charger |
| Compatible charger family | Fits SB510 and SB511 charger arrangements |
| Storage care | Spare batteries should be recharged at six-month intervals with the specified charger |
| Confirm the installed charger and maintenance interval before purchasing. | ASK MIYA TO CHECK |
| AC 400 controller | Holds operating memory | Protected equipment |
| SB510 / SB511 | Battery-charger role | Controls charge and discharge |
| SB522V1 | 12 V, 4 Ah NiMH reserve | Selected battery unit |
| SB518 service charger | Used for stored spare batteries | Periodic recharge role |
Physical similarity alone does not establish interchangeability. Confirm the complete catalog number, installed system and electrical or mechanical configuration together.
| EMAIL · SALES@AMIKON.CN | WHATSAPP · 86-18020776792 | SALES MANAGER · MIYA ZHENG |
| Contact us within seven days if a concern appears after receipt. | Keep the item in its original condition and state the reason. Resolution follows receipt and inspection. | Return-related shipping charges are paid by the buyer. |
| 01 |
SB522V1 3BSC760015R1 — Can SB522V1 3BSC760015R1 be installed without checking the charger?
No. Confirm the installed AC 400 arrangement and compatible charger before connection; the battery is part of a managed backup circuit.
|
| 02 |
SB522V1 3BSC760015R1 — How should a stored SB522V1 3BSC760015R1 be maintained?
ABB calls for spare batteries in storage to be recharged every six months with the specified SB518 charger arrangement.
|
| 03 |
SB522V1 3BSC760015R1 — What should be inspected before ordering SB522V1 3BSC760015R1?
Check the full product ID, battery label, connector and lead condition, installed charger type, mounting arrangement and maintenance history.
|
| 04 |
SB522V1 3BSC760015R1 — Does SB522V1 3BSC760015R1 power the whole controller?
Its stated role is backup current supply for RAM. It is not a substitute for the normal controller power supply.
|
| 05 |
SB522V1 3BSC760015R1 — What precautions apply when replacing SB522V1 3BSC760015R1?
Follow site battery-handling rules, preserve RAM backup continuity where required, prevent short circuits and confirm polarity before connection.
|
