ABB JC2000-0049 Three-Axis FlexPendant Joystick Assembly

ABB JC2000-0049
ABB JC2000-0049
ABB JC2000-0049

ABB JC2000-0049 Three-Axis FlexPendant Joystick Assembly

Calculate shipping
Quotation Request


ABB / ROBOTICS
JC2000-0049

TEACH PENDANT
Joystick control component
✣   ⊕   ↗
ROBOT MOTION

CONTROL COMPONENT
MODEL IDENTIFICATION / 01
01 Part number
JC2000-0049
02 Component type
Joystick
03 Application
Robot teach pendant control


AMIKON SERVICE
Global Parts Support
International Delivery on the Day
Quick Response Support
Intercontinental Cooperation Network
Sales manager: Miya zheng
ABB ROBOTICS / P&G CONTROLS PRODUCTSYSTEM FITSUPPLYFAQMODELS


X
Y / Z
OPERATOR MOTION CONTROL

JC2000-0049

Three-Axis FlexPendant Joystick Assembly

Used in the ABB DSQC679 FlexPendant, this joystick converts operator hand movement into proportional electrical commands for controlled robot jogging.
+01  THREE AXES
+02  PLUS GATE
+03  IP65 FRONT
+04  DSQC679
MOVE  /  CENTER  /  RETURN
+ PRODUCT DETAIL

Role, Hardware and Operating Fit

JC2000-0049

JC2000-0049 is the motion-command joystick inside the DSQC679 FlexPendant used with ABB IRC5 robot systems. Its three-axis movement lets an operator request directional jogging from the pendant. It is a service component, so electrical centering, mechanical return and pendant compatibility are central purchasing checks.

Manufacturer: ABB ROBOTICS / P&G CONTROLS
Product type: Three-Axis FlexPendant Joystick Assembly

Product class Three-axis joystick assembly
ABB spare-part relation 3HAC028357-026
Pendant relationship DSQC679 FlexPendant, 3HAC028357-001
Output form Single output, +/-1.25 VDC about center voltage
Handle and gate Straight handle, plus gate
Operating temperature -25 to +70 deg C
Front protection IP65 configuration
Primary function Operator robot motion command
01 / Three-axis control

One compact control supports proportional motion requests in three axes.


02 / Sealed operator interface

The specified configuration uses an IP65 front arrangement for demanding handheld operation.


03 / Pendant serviceability

A failed joystick can be addressed as an assembly instead of replacing the complete FlexPendant when the rest of the unit is serviceable.
Confirm the complete installed configuration
Confirm the DSQC679 pendant identity, ABB spare-part relation, connector and harness condition, center output, axis response, gate geometry and mechanical return before replacement.		 REQUEST A QUOTE >
X SERIES / SYSTEM RELATIONSHIP

Select by System Role and Catalog Code

MODEL SYSTEM POSITION PURCHASING DISTINCTION
JC2000-0049 Three-axis joystick assembly DSQC679 / IRC5 FlexPendant
3HAC028357-026 ABB spare-part relation Joystick assembly identifier
3HAC028357-001 DSQC679 FlexPendant Complete handheld operator unit
DSQC679 system Pendant platform Includes display, controls, cable and safety devices
Selection checkpoint
Confirm the DSQC679 pendant identity, ABB spare-part relation, connector and harness condition, center output, axis response, gate geometry and mechanical return before replacement.
+ 20 YEARS OF INDUSTRIAL AUTOMATION SUPPLY

Experienced Support for Urgent Requirements

Quality and Experience

AMIKON supports current, scarce and discontinued automation requirements with responsive communication and careful order checks.


Inspection Awareness
Catalog-code and condition checks help reduce ordering mistakes.

Urgent Dispatch Support
Fast handling options support recovery from unplanned downtime.
@ DIRECT CONTACT

Keep the Requirement Moving

MIYA ZHENG - SALES MANAGER SALES@AMIKON.CN WHATSAPP +86 180 2077 6792
Contact within seven days
Raise any concern promptly after receipt.		   Keep original condition
State the return reason and preserve the item.		   Resolution after inspection
Buyer covers return-related shipping costs.
? PURCHASING FAQ

Five Checks Before Ordering

01
JC2000-0049: Is JC2000-0049 a complete ABB FlexPendant?
No. It is the joystick assembly used inside the DSQC679 FlexPendant.

02
JC2000-0049: Which ABB spare-part number is associated with JC2000-0049?
The joystick assembly is commonly related to ABB number 3HAC028357-026 for the DSQC679 pendant.

03
JC2000-0049: What should be tested before installing JC2000-0049?
Check center stability, proportional response on all three axes, spring return, connector integrity and physical gate movement.

04
JC2000-0049: Can JC2000-0049 be selected only from its appearance?
No. Confirm the pendant model, ABB spare-part relation, electrical output, connector and mechanical configuration.

05
JC2000-0049: What should be verified after JC2000-0049 replacement?
With approved robot safety procedures, verify neutral state, direction mapping, proportional jogging, return to center and absence of unintended movement.
