ABB 3HAC17396-1 Serial Measurement Unit

ABB 3HAC17396-1
ABB 3HAC17396-1
ABB 3HAC17396-1

ABB 3HAC17396-1 Serial Measurement Unit

Calculate shipping
Quotation Request
3HAC17396-1
TYPE
DSQC 562 ⇒ ABB robot measurement assembly

ASSEMBLY TYPE
Serial Measurement Unit

BOARD INSIDE
3HAC031851-001

BATTERY PACK
3HAC16831-1
Restore the robot's measurement chain with confidence.
A dedicated SMB assembly for maintenance situations involving serial measurement hardware.
SALES MANAGER: MIYA ZHENG
sales@amikon.cn
86-18020776792
ABB ROBOTICS Overview Technical Application FAQ Contact

ABB ROBOTICS / SERIAL MEASUREMENT
3HAC17396-1

Serial Measurement Unit
Configured for the ABB IRB 2400 platform with the serial measurement board and battery arrangement associated with this part number.
SYSTEM
IRB 2400
BOARD
3HAC031851-001
BATTERY
3HAC16831-1

CONFIGURATION CORE
SMB / RMU
Part-number matching is essential because ABB specifies different serial measurement unit and battery combinations.
PART ROLE
Serial Measurement Unit
PLATFORM
ABB IRB 2400
ASSEMBLY
Board + Battery Pack
TECHNICAL PROFILE
3HAC17396-1 configuration
Part number 3HAC17396-1
Unit type Serial measurement unit
Robot family IRB 2400
Measurement board 3HAC031851-001
Battery pack 3HAC16831-1
Matching point Complete installed assembly
ABB identifies different SMB variants and battery arrangements. The replacement must retain the correct combination rather than mixing battery-contact versions.
ROBOT APPLICATION
Measurement continuity on IRB 2400
The serial measurement unit supports the robot's measurement architecture. During service, the exact installed unit and battery arrangement matter because the robot relies on stored axis measurement data for correct operation.
A failed SMB path, depleted battery arrangement, or incompatible replacement can turn a routine maintenance task into a longer restoration process and may keep the robot unavailable until the measurement system is correctly restored.
BUYER CHECKPOINT
Before replacement
01 — Match the full part number.
02 — Confirm robot model and serial record.
03 — Compare installed board and battery identifiers.
04 — Verify the battery-contact arrangement.
05 — Confirm the required service procedure.
PURCHASING CONTACT
Confirm 3HAC17396-1 before ordering
Please provide Part Number, Quantity, Destination, Required Date and Machine/System for quotation.
 Email: sales@amikon.cn Phone / WhatsApp: 86-18020776792
