ABB INDUSTRIAL ROBOTICS / MANIPULATOR SPARE PART
3HAC022544-001
Manipulator Harness Axis 1–6
The ABB 3HAC022544-001 is identified as the manipulator harness for axes 1–6 in the IRB 760 robot spare-parts structure. It is a robot-body harness rather than a controller electronics module, making correct robot-model matching particularly important before replacement.
|
ABB
PRODUCT PROFILE
01 Robot-body wiring component
|
|
01 / COMPONENT
Manipulator Harness
Axis 1–6 robot harness assembly.
|
02 / PLATFORM
ABB IRB 760
Listed within the IRB 760 spare-parts structure.
|
03 / POSITION
Axis 1–6
Internal manipulator cable routing.
|
|
TECHNICAL MATCH
Match the robot
before ordering. |
Important matching point: 3HAC022544-001 is associated with the IRB 760. The IRB 760 spare-parts manual separately identifies 3HAC022544-001 as the axis 1–6 manipulator harness. For IRB 660 applications, the corresponding harness reference is 3HAC022544-008, so the robot model should be checked before purchasing.
|
|
APPLICATION CONTEXT
When the robot body becomes the weak point.
In an IRB 760 installation, the manipulator harness forms part of the robot-side wiring associated with axes 1–6. Because the harness moves with the manipulator, cable condition can become an important maintenance consideration over long operating periods. A replacement search for 3HAC022544-001 is therefore more likely when a robot develops intermittent electrical behaviour, wiring damage, or harness-related maintenance issues rather than when a controller board itself has failed. |
|
|
INDUSTRIAL PARTS SUPPORT
Spare parts support built around uptime.
Amikon focuses on industrial automation components and robot spare parts, supporting maintenance teams that need to identify and replace critical components without unnecessary delay. |
|
|
AUTOMATION PORTFOLIO
Beyond one robot spare part.
|
|
|
PURCHASE CHECK
Five questions worth checking before replacement.
|
01 — Is ABB 3HAC022544-001 intended for my robot?
It is identified as the manipulator harness for axes 1–6 in the IRB 760 spare-parts structure. If your robot is an IRB 660, do not substitute this part based only on the similar “axis 1–6” description; the IRB 660 uses a different harness reference.
02 — Why does ABB 3HAC022544-001 matter when the robot fault appears intermittent?
A manipulator harness moves with the robot body, so wiring-related symptoms may become more noticeable during motion than while the robot is stationary. This makes correct harness identification useful when maintenance teams are investigating movement-dependent electrical faults.
03 — Is ABB 3HAC022544-001 the same part used on the IRB 660?
No. The IRB 760 spare-parts structure identifies 3HAC022544-001, while the IRB 660 is associated with 3HAC022544-008. The two part numbers should not be treated as interchangeable simply because both relate to axes 1–6.
04 — What should I verify before ordering ABB 3HAC022544-001?
Confirm the robot model, the existing harness part number, and the intended replacement position. For an IRB 760 maintenance job, matching the robot family is more useful than relying on a generic cable description alone.
05 — When should ABB 3HAC022544-001 be considered for a planned spare?
It can be considered when an IRB 760 production cell cannot tolerate extended downtime caused by a robot-body harness issue. Keeping the correctly matched harness available can shorten the time between fault confirmation and mechanical replacement.
|
|
ORDER SUPPORT
Tell us what the robot needs.
|
For a faster quotation, please provide:
Delivery: 3–5 days | Condition: Brand New | Warranty: 12 Months
Delivery way: E-packing / FedEx / EMS / TNT / DHL / UPS Payment: T/T
|
|
CONTACT AMIKON
Need the right part?
Send the complete part number and robot/system details. Our sales team can check the matching requirement with you.
|
|
|
AFTER-SALES
Return & Replacement
|
Please contact us within 7 days after receiving the item if there is any question. Returned items should remain in their original condition and be accompanied by the specific reason for return. After the returned item is received, a return or replacement can be arranged according to the case. Shipping costs incurred for the return are the buyer's responsibility.
|
| AMIKON | Industrial Automation & Robot Spare Parts | ABB 3HAC022544-001 |
