YOKOGAWA FLXA21-D-P Liquid Analyzer 24 VDC

YOKOGAWA FLXA21-D-P
YOKOGAWA FLXA21-D-P
YOKOGAWA FLXA21-D-P

YOKOGAWA FLXA21-D-P Liquid Analyzer 24 VDC

Calculate shipping
Quotation Request



YOKOGAWA / LIQUID ANALYSIS
FLXA21-D-P
FLXA21 is a modular 2-wire analyzer platform for continuous industrial liquid measurement.
MODULAR ANALYZER PLATFORM
The FLXA21 family supports pH/ORP, contacting conductivity, inductive conductivity and dissolved oxygen measurement configurations.
CORE PARAMETERS
2-Wire
Analyzer
16–40 V DC
1-Sensor Supply
IP66
Housing Rating
COMPACT FIELD ANALYSIS
The FLXA21 uses a polycarbonate housing, anti-glare LCD touch screen and supports a 12-language display environment. The platform can be configured for single- or dual-sensor measurement depending on the selected input arrangement.
We have a wide range of brands and products for various industries, we provide services to tens of thousands of customers around the world.
CONTACT
✉ Miya zheng ◉ Phone / WhatsApp
2-WIRE / LIQUID ANALYSIS



YOKOGAWA • TWO-WIRE LIQUID ANALYSIS
FLXA21-D-P
2-Wire Modular Transmitter / Analyzer Platform

MODULAR ARCHITECTURE  •  LOOP POWERED  •  DIGITAL COMMUNICATION  •  ONLINE DIAGNOSTICS
PRODUCT OVERVIEW
FLXA21-D-P
The YOKOGAWA FLXA21 is a modular two-wire liquid analyzer designed for continuous online measurement in industrial installations. Its architecture combines a housing assembly with one or two sensor modules, allowing the analyzer configuration to be matched to the required measurement technology.
Depending on the installed sensor module, the FLXA21 platform supports pH/ORP, contacting conductivity, inductive conductivity, and dissolved oxygen measurement. Two compatible sensor modules can be installed for selected same-type combinations, including pH/ORP + pH/ORP, SC + SC, and DO + DO.
The FLXA21 uses a 2-wire 24 VDC loop-powered architecture and can communicate through HART, with FOUNDATION Fieldbus and PROFIBUS PA available in applicable configurations.

CONFIGURATION SNAPSHOT
Platform FLXA21
Power 2-wire / 24 VDC loop
Housing Plastic / Polycarbonate
Protection IP66 / NEMA 4X
Display Anti-glare LCD

ENGINEERED AROUND MODULAR MEASUREMENT
01
Dual-Sensor Architecture
One housing can accommodate one or two sensor modules, with defined same-type combinations for selected applications.
02
Continuous Diagnostics
For pH/ORP applications, detector impedance, asymmetric potential and slope can be monitored for condition assessment.
03
Loop-Powered Design
The 2-wire 24 VDC architecture combines measurement and process communication in a compact industrial analyzer platform.
04
Flexible Communication
HART communication is supported, with FOUNDATION Fieldbus and PROFIBUS PA available for applicable FLXA21 configurations.
pH / ORP MEASUREMENT
The pH/ORP measurement configuration provides dual high-impedance input with input impedance of at least 1012 Ω.
pH range -2 to 16 pH
ORP range -1500 to +1500 mV
rH range 0 to 100 rH
pH accuracy ±0.01 pH
ORP accuracy ±1 mV
CONTACTING CONDUCTIVITY
The SC configuration uses two- or four-electrode measurement with square-wave excitation and supports cell constants from 0.005 to 50.0 cm-1.
Cable distance Up to 60 m / 200 ft
Cell constant 0.005 to 50.0 cm-1
Display conductivity 0.01 µS/cm to 2000 mS/cm
Resistivity 0.001 kΩ·cm to 1000 MΩ·cm
TECHNICAL CHARACTERISTICS
Analyzer structure One housing assembly with one or two sensor modules
Power supply 2-wire, 24 VDC loop powered
Output Bi-directional HART digital communication superimposed on 4–20 mA
Optional communication FOUNDATION Fieldbus / PROFIBUS PA in applicable configurations
Housing material Polycarbonate
Enclosure protection IP66 / NEMA 4X / CSA 3S
Languages 12 selectable languages
Display Anti-glare LCD touch-screen interface
Area classification options General purpose, Class I Div II, Class I Div I with applicable safety arrangement
TEMPERATURE COMPENSATION
Temperature measurement and compensation depend on the installed measurement module and sensor configuration.
pH/ORP temperature Pt1000, Pt100, 6.8k, PTC10k, NTC 8k55, 3k Balco, PTC500
Typical accuracy ±0.3 °C for specified sensor types; ±0.4 °C with Pt100
SC temperature Pt1000, Pt100, Ni100, NTC 8k55, Pb36/JIS NTC 6k
DIAGNOSTIC FUNCTIONS
FLXA21 provides advanced diagnostic functions designed to help operators assess sensor condition and maintenance requirements during continuous operation.
Sensor condition: pH/ORP detector impedance, asymmetric potential and slope can be monitored continuously.
Calibration history: the latest five calibration results are retained for maintenance assessment.
Quick setup: guided screen functions support initial configuration and commissioning.
◈
WHERE THE FLXA21 PLATFORM FITS
PROCESS WATER
Suitable measurement configurations can support water-quality monitoring where continuous pH, conductivity, resistivity or dissolved-oxygen measurement is required.
CHEMICAL PROCESS
The modular sensor architecture allows the analyzer platform to be configured around the measurement technology required by the process.
UTILITY & TREATMENT
Loop-powered operation and industrial enclosure protection make the FLXA21 suitable for distributed online analyzer installations.
FLXA21 FAMILY CONFIGURATION VIEW
The FLXA21 family is built around a common two-wire analyzer platform. Model configuration is determined through power, housing, display, sensor-input and communication suffixes.
FLXA21-D-P
2-wire analyzer platform with -D power designation and plastic housing designation.
Sensor Modules
pH/ORP, contacting conductivity, inductive conductivity and dissolved oxygen modules are available according to configuration.
Communication
HART is supported, while FOUNDATION Fieldbus and PROFIBUS PA are available for applicable variants.
Application Choice
Selection should be matched to sensor technology, hazardous-area requirements and communication architecture.
PURCHASING CHECKPOINT FOR FLXA21-D-P
Before replacement or system integration, confirm the installed sensor module, communication requirement, display configuration, hazardous-area classification, power-loop arrangement and sensor wiring. The FLXA21 suffix structure determines important configuration details, so the complete existing model code should be matched before ordering.
CONTACT & ORDER SUPPORT
YOKOGAWA FLXA21-D-P
For replacement inquiries, configuration checks and industrial automation spare-part requirements, please provide the complete model code and required quantity.
Delivery 3–5 days
Warranty 12 months
Payment T/T
INQUIRY DETAILS
Part Number  •  Quantity  •  Destination  •  Required Date  •  Machine / System
RETURN / REPLACEMENT POLICY
Please contact us within 7 days if you have any question after you receiving the items.
The returned items has to be in its original condition, specific reason for the return, we will issue a return or replacement for your order after we received the returns.
The buyer is responsible for all the shipping cost incurred.
FLXA21-D-P FAQ
01 · Can FLXA21-D-P replace another FLXA21 unit directly?
A direct replacement should not be assumed from the FLXA21 family name alone. The sensor module, communication type, area classification, display configuration and complete suffix code should be matched with the existing installation before replacement.
02 · Does FLXA21-D-P support two measurement points?
The FLXA21 platform can use one or two sensor modules. Two-module operation is available for defined same-type combinations such as pH/ORP + pH/ORP, SC + SC and DO + DO. The actual replacement configuration must match the installed module arrangement.
03 · Is FLXA21-D-P suitable for a loop-powered replacement project?
The FLXA21 platform uses a 2-wire 24 VDC loop-powered architecture. For an existing installation, verify the loop supply, signal wiring and communication arrangement before replacing the analyzer.
04 · Which sensor technologies can FLXA21-D-P be configured around?
The FLXA21 platform supports pH/ORP, contacting conductivity, inductive conductivity and dissolved oxygen measurement through the corresponding sensor-module configuration. The installed module determines the available measurement function.
05 · What should be checked when ordering FLXA21-D-P for an existing system?
Check the complete model code, installed sensor module, communication method, hazardous-area requirements, power arrangement, display configuration and sensor wiring. These details determine whether the replacement matches the existing process loop and measurement architecture.
