ET5*C accepts a thermocouple input, applies reference-junction compensation and configured scaling, then provides two isolated-use 1–5 V DC output paths for connected instrumentation.
Suffix /BU: upscale burnout · /BD: downscale burnout · /DF: Fahrenheit display.
| Accepted sensors | K, T, J, E, B, R, S, N thermocouples |
| Analog output | 1–5 V DC × 2 |
| Load / output resistance | ≥ 2 kΩ / ≤ 1 Ω |
| External input resistance | ≤ 500 Ω |
| Dimensions / mass | 73 × 24 × 115 mm / approx. 70 g |
| Connection | Dedicated nest connector · M4 field terminals |
Condition temperature signals from vessels, piping and thermal equipment.
Feed stable temperature values into monitoring and control instruments.
Maintain installed signal-conditioning assemblies and spare strategies.
K, T, J, E, B, R, S and N input types are listed in the official specification.
Correct reference-junction compensation depends on the specified connector arrangement.
Configuration supports Celsius, Fahrenheit or Kelvin; /DF identifies Fahrenheit display.
Burnout behavior can drive the signal upscale or downscale according to configuration.
Confirm the complete suffix, thermocouple type, required range, display unit and burnout direction.
