EH0 accepts a 1–5 V DC input, isolates the signal, and provides one 1–5 V DC output for Yokogawa signal-conditioner applications.
|
1–5 V
DC INPUT |
→ |
EH0*A
GALVANIC ISOLATION |
→ |
1–5 V
1-POINT OUTPUT |
| TECHNICAL DATA
Official
specification snapshot Yokogawa GS 33J60H80-01EN |
|
| Legacy DCS maintenance Maintain installed Yokogawa signal-conditioning assemblies. |
Voltage signal isolation Separate a 1–5 V control signal from the receiving circuit. |
Noise and loop protection Support stable signal transfer in process-control cabinets. |
Like-for-like spares Source the correct suffix for an existing special nest. |
| 01 · What does EH0 do?
It isolates a 1–5 V DC input and produces one 1–5 V DC output. |
02 · Where is it mounted?
In a special Yokogawa signal-conditioner nest using its backboard connector. |
| 03 · Can any EH0 suffix be substituted?
The complete suffix and installed hardware should be checked before substitution. |
04 · What load is specified?
The official specification states an output load resistance of 2 kΩ or more. |
| 05 · What should be sent with an inquiry? A clear nameplate photo, full EH0*A code, installed nest details and required quantity. |
|
