A rack-mounted network bridge connecting Vnet/IP stations to dual-redundant V net stations. The Q220 configuration combines dual V net paths, dual power supplies and a 220–240 V AC supply for high-availability CENTUM architectures.
| Network roleVnet/IP to dual-redundant V net routing | V net side10 Mbps coaxial, BNC T-junction | Vnet/IP side100 Mbps full duplex, 100Base-TX |
| Network role | Vnet/IP to dual-redundant V net routing |
| V net side | 10 Mbps coaxial, BNC T-junction |
| Vnet/IP side | 100 Mbps full duplex, 100Base-TX |
| Vnet/IP cable | CAT5e or better, RJ45 |
| Maximum Ethernet segment | 100 m to Layer 2 switch |
| Power arrangement | Dual power supply |
| Supply voltage | 220 to 240 V AC, 50/60 Hz |
| Power consumption | 110 VA |
| Mounting / weight | 19-inch rack / approximately 5.8 kg |
| Confirm availability and the complete suffix before purchase | REQUEST A QUOTE |
Products in the same family can differ in network role, mechanical form, power arrangement, I/O capacity, sensing material or cable length. Match every field before treating another model as a replacement.
| MODEL | DISTINCTION | BUYING CHECK |
| AVR10D-Q220 | Dual V net + dual 220–240 V AC supply | Selected configuration |
| AVR10D-Q210 | Dual V net + single 220–240 V AC supply | No power duplication |
| AVR10D-Q224 | Dual V net + dual 24 V DC supply | Different power source |
| AVR10D-A2xx | Dual VL net path | CENTUM CS 1000 connection role |
|
