32-Channel • 24 V DC • Isolated • SOE Capture • Status Display
ORDER CODE BREAKDOWN
ADV151 / -E / 6 / 0 / D5A00
The ADV151 family provides 32 isolated 24 V DC digital input channels. The -E suffix provides SOE capture, 6 specifies the status-display version without explosion protection, 0 is the basic type, and /D5A00 specifies the ATD5A-00 KS cable interface adapter.
CONFIGURATION SNAPSHOT
Input architecture
32 isolated channels
Rated field input
24 V DC sink/source
SOE function
Supported
Interface adapter
ATD5A-00
Looking for another industrial automation component? Send the Part Number + Quantity + Destination + Required Date + Machine/System to our sales team.
ADV151-E60/D5A00 is a Yokogawa FIO digital input configuration designed to receive 32 channels of isolated 24 V DC ON/OFF signals. Its -E configuration adds sequence-of-events capture, making the module suitable where the order and timing of discrete field-state changes matter during process operation and event investigation.
Why the exact suffix matters
The complete order code is more than a basic ADV151 reference. The -E selection provides SOE capture, the 6 selection provides a front status display without explosion protection, and /D5A00 specifies the ATD5A-00 interface arrangement. For replacement work, matching the complete suffix and connection method helps avoid an otherwise unnecessary change to the field-side wiring arrangement.
CORE PROFILE
Module family
ADV151
Input channels
32
Input type
24 V DC
Isolation
Isolated
SOE capture
Yes
Status display
Yes
FUNCTIONAL HIGHLIGHTS
Designed Around Discrete Event Capture
32
Isolated Input Channels
The ADV151 platform handles 32 isolated digital inputs with a 24 V DC rated field signal.
SOE
Sequence-of-Events Capture
The -E configuration provides SOE input functionality for capturing sequence-of-events data.
ATD5A
KS Cable Interface
/D5A00 specifies the ATD5A-00 KS Cable Interface Adapter for the 32-channel digital input connection.
TECHNICAL PROFILE
ADV151-E60/D5A00 Specifications
Parameter
Specification
Number of input channels
32
Rated input voltage
24 V DC, sink/source
Input ON voltage
18 to 26.4 V DC
Input OFF voltage
5.0 V DC or less
Input current at rated voltage
4.1 mA ±20% / channel
Maximum allowable input voltage
30.0 V DC
Input-to-system withstand voltage
2 kV AC, 1 minute
Common withstand voltage
500 V AC, 1 minute; common every 16 channels
Status input response time
8 ms or less
Maximum current consumption
500 mA at 5 V DC
Weight
Approx. 0.30 kg
External connection options
Pressure clamp terminal / dedicated cable / MIL connector cable
Installation note: ADV151-E is not permitted in the ER Bus Node Unit. Its SOE capture function is intended for use when the module is installed in the FIO local node. For 24 V DC voltage inputs, the signals connected to each common group must have the same polarity.
SERIES POSITION
ADV151 Family Configuration Logic
ADV151-P
32-channel, 24 V DC isolated digital input with pushbutton input functionality.
ADV151-E
32-channel, 24 V DC isolated digital input with SOE capture. This is the functional family of ADV151-E60/D5A00.
ADV161
64-channel, 24 V DC isolated digital input for projects requiring a larger channel count.
ADV151 Options
Connection choices include /D5A00, /B5S00, /B5S10, /B5D00, /B5D10 and /CCC01.
When the complete ADV151-E60/D5A00 configuration is important
A replacement should not be selected only by the ADV151 base number. If the existing installation uses SOE capture, a status display, the basic non-explosion-protected configuration and the ATD5A-00 KS cable interface arrangement, the complete ADV151-E60/D5A00 code is the more relevant matching point.
APPLICATION FIT
Where This Configuration Adds Practical Value
Event-sensitive digital input
When discrete field changes need to be captured as sequence-of-events data rather than treated only as ordinary ON/OFF states, the -E configuration provides the required SOE input function.
Replacement of an existing ADV151-E configuration
For maintenance replacement, the critical checks include the 32-channel count, 24 V DC field level, SOE requirement, status-display selection, installation node limitations and the ATD5A-00 connection arrangement.
Signal integrity and isolation
The input architecture is isolated, with common grouping every 16 channels. The 24 V DC signals connected to each common group must use the same polarity.
Configuration-sensitive procurement
The connection option is part of the order code. /D5A00 means the ATD5A-00 KS cable interface adapter, while other ADV151 suffixes use different field connection arrangements.
DIRECT PROCUREMENT CHANNEL
ADV151-E60/D5A00 — Request a Quote
Send the complete model and project details for a configuration-focused quotation.
Q1. Does ADV151-E60/D5A00 preserve the SOE function required by an existing ADV151-E installation?
Yes. The -E configuration is the ADV151 version with SOE capture. The exact E60 configuration also includes the status-display selection and basic type. For a replacement where event capture is part of the control-system design, the complete E60 suffix should be matched rather than ordering only the ADV151 base model.
Q2. Is ADV151-E60/D5A00 the right replacement when the cabinet already uses an ATD5A-00 connection?
The /D5A00 option specifically selects the ATD5A-00 KS Cable Interface Adapter for the 32-channel digital input arrangement. If the existing cabinet uses a different terminal or cable option, the connection code should be checked before purchase instead of assuming all ADV151 variants use the same field-side interface.
Q3. What should be checked electrically before purchasing ADV151-E60/D5A00 as a replacement?
The field circuit should match the 24 V DC sink/source input arrangement. The specified ON range is 18 to 26.4 V DC, the OFF threshold is 5.0 V DC or less, and the maximum allowable input voltage is 30.0 V DC. The module also uses common grouping every 16 channels, so the polarity requirement for the connected 24 V DC voltage inputs should be checked during replacement planning.
Q4. Can ADV151-E60/D5A00 be selected when the existing FIO installation is in an ER Bus Node Unit?
No. The ADV151-E configuration has an installation limitation: it cannot be installed in the ER Bus Node Unit. In addition, the SOE capture function is intended for use when the ADV151-E is installed in the FIO local node. This installation point should therefore be confirmed before treating the module as a direct replacement.
Q5. When should a buyer choose ADV151-E60/D5A00 instead of a different ADV151 suffix?
ADV151-E60/D5A00 is specifically suited when the project requires the SOE capture function, the status-display version, the basic type without explosion protection, and the ATD5A-00 KS cable interface. Other ADV151 suffixes change the input function, display/explosion-protection configuration, environmental option or field connection method, so the existing configuration should determine the exact replacement code.
