AAI143
Analog Input
|
-H
HART Communication
|
5
No Explosion Protection
|
0
Basic Type
|
/K4A00
ATK4A-00 Adapter
|
The AAI143 receives 4–20 mA field signals through 16 isolated input channels. Its specified accuracy is ±16 μA, with a 10 ms data update period. Input current is permitted up to 24 mA, while the field-to-system withstand voltage is specified at 1500 V AC for one minute.
Each channel can be configured for a 2-wire or 4-wire transmitter by setting pin. The module can also be used in a dual-redundant configuration, making the model relevant where signal acquisition and continuity need to be considered together.
| 01 / INPUT | 4–20 mA | 02 / CHANNELS | 16 isolated |
| 03 / ACCURACY | ±16 μA | 04 / UPDATE | 10 ms |
| Parameter | AAI143-H50/K4A00 Specification |
| Module type | Analog Input Module, 4–20 mA, 16-channel, isolated |
| Input signal | 4–20 mA |
| Number of input channels | 16, isolated |
| Allowable input current | 24 mA |
| Withstand voltage | 1500 V AC between input and system, 1 minute |
| Input resistance, power ON | 270 Ω at 20 mA to 350 Ω at 4 mA |
| Input resistance, power OFF | 500 kΩ or larger |
| Accuracy | ±16 μA |
| Data update period | 10 ms |
| Transmitter power supply | 19.0 V or higher at 20 mA; 25.5 V or less at 0 mA; output current limit 25 mA |
| Transmitter setting | 2-wire or 4-wire transmitter setting by channel |
| Temperature drift | ±16 μA / 10 °C |
| Maximum current consumption | 230 mA at 5 V DC; 540 mA at 24 V DC |
| HART communication | Available |
| Redundancy | Dual-redundant configuration supported |
| Cable interface | KS Cable Interface Adapter, ATK4A-00, for AEA4D terminal board |
|
SERIES POSITION
AAI143 Family
AAI143 is the isolated current-input member of Yokogawa's analog I/O range for FIO systems. The series provides different suffix combinations so the input function, explosion-protection configuration, environmental option and field-side interface can be matched to the installation. |
|
|
When HART capability is part of the requirement
The “-H” suffix is specifically associated with digital communication using HART protocol. This makes the H50 configuration relevant when the existing control architecture requires HART-capable analog input handling, rather than only conventional 4–20 mA signal acquisition. |
When the field interface already uses AEA4D
The /K4A00 option specifies the ATK4A-00 KS Cable Interface Adapter for connection to an AEA4D terminal board. For replacement projects, checking the existing terminal-board and cable arrangement is therefore an important part of model selection. |
|
When redundant operation is considered
AAI143 can be used in a dual-redundant configuration. This makes the module relevant to installations where maintaining the signal-acquisition path is part of the control-system design. |
Replacement check before purchase
Do not select by the base model alone. Confirm the HART requirement, explosion-protection configuration, basic or environmental option, terminal-board arrangement and cable interface before placing an order. |
|
Ready to Check Availability?
Send the exact part number and project requirements. Our team can check the model configuration, quantity and delivery arrangement before quotation. |
|
||||
| Delivery 3–5 days |
Warranty 12 months |
Packaging Brand New |
Payment T/T |
Shipping E-packing / FedEx / EMS / TNT / DHL / UPS |
