GOVERNOR SPEED ARC
CCW DRIVE
|
TG-13 / MECHANICAL-HYDRAULIC CONTROL
Woodward
|
OUTPUT TRAVEL
12
FT-LB WORK OUTPUT
LEGACY TG-13
TG611-13 MIGRATION |
| Manufacturer | Woodward |
| Part number | 8516-038 |
| Product type | TG-13 mechanical-hydraulic governor |
| Speed setting | Screw adjustment |
| Drive rotation | Counter-clockwise |
| Preferred successor | 8516-175 |
|
SYSTEM
|
The governor senses shaft speed through its mechanical drive and adjusts the fuel or steam control linkage through hydraulic work output. Its installed calibration, drive rotation and linkage travel determine how the prime mover responds to speed changes. |
| Work output | 12 ft-lb |
| Rated speed | 2400 rpm |
| High speed at 2-degree setting | 2900 rpm |
| Rated speed at 38-degree setting | 1800 rpm |
| Rated speed at 2-degree setting | 2010 rpm |
| Low speed at 2-degree setting | 1200 rpm |
| Drive rotation | Counter-clockwise |
| Adjustment form | Screw speed setting |
|
Mechanical input
Prime-mover governor drive
|
Control core
Flyweight and hydraulic governor mechanism
|
Mechanical output
Work linkage to fuel or steam control
|
System effect
Closed-loop prime-mover speed regulation
|
| 8516-038 | This page: TG-13, 2400 rpm, CCW |
| 8516-175 | Preferred TG611-13 successor with 12 ft-lb output |
| 9904-814 | TG13 2400 rpm related migration option |
| A8516-038 / B8516-038 / C8516-038 | Rotation and calibration variants; not automatic substitutes |
