Manufacturer |
Woodward |
|
Model |
8440-1809 |
|
Series |
EASYGEN-1000 |
|
Type |
Genset Control |
|
Power supply |
12/24 Vdc (6.5 to 40.0 Vdc) |
Genset Control for Single Unit Operation
APPLICATIONS
The 2nd Generation of genset controls is designed to provide a maximum of flexibility in a user friendly and intuitive design with a large graphical display for various applications. This controller is one of a series of new and powerful genset controls (easYgen). This trend-setting technology offers a maximum of flexibility for each user. New technologies included are:
FlexAppTM - This intelligent and flexible feature provides the tools to easily configure for multiple applications. The user can configure the easYgen-1000 Series for use as
l Measuring transducer/engine control [0-CB-Mode {0}] for start/stop and measuring conversion
l 1-breaker-control [GCB open, {1o}] above plus engine/generator protection
l 1-breaker-control [GCB open/close, {1oc}] above plus stand-by power applications
l 2-breaker-control [GCB/MCB open/close, {2oc}] above plus AMF, and open transition applications
DynamicsLCDTM - The graphical LCD provides softkeys that vary depending on application and operation.
FlexInTM - The two analog inputs can be freely configured (adaptable for each type of sensor) by the user as:
l VDO (0 to 180Ohm [0 to 5bar/0 to 10bar]; 0 to 380Ohm [40 to 120°C/50 to 150°C]; 0 to 180 Ohm [0 to 100% level]; isolated (2- pole) and non-isolated (1-pole) ground senders only)
l Resistive input (Pt100 / linear 2point / user-defined 9point)
l 0/4 to 20 mA (linear 2point / user-defined 9point)
FlexCANTM - Flexible isolated CAN bus for multiple use. Selectable during configuration: CANopen, or CAN (CAL); coupling of easYlite remote annunciator; coupling of 3rd party expansion cards supported.
J1939 protocol for ECU coupling and alarm management, remote start/stop with ECU possible (Scania, Volvo, Deutz, mtu).
LogicsManagerTM - A large number of measuring values, inputs, internal states or constant values can be combined logically to operate a relay contact or an internal function.
DESCRIPTION
I/Os
l FlexRangeTM - true RMS 3phase generator and mains voltage, measuring inputs:
o Rated 120 Vac (max. 150 Vac) and
o Rated 480 Vac (max. 600 Vac) in 1 unit
l True rms 3phase generator current/power
l True rms 1phase current input alternatively and freely configurable for
o Mains current
o Ground current (ground fault protection)
l 1 speed input (magnetic/switching)
l up to 8 configurable discrete alarm inputs
l LogicsManagerTM - up to 9 program. relays
l FlexInTM - 2 configurable analog inputs
l FlexCANTM - CAN bus communication (32 participants, isolated)
Features
l FlexAppTM Technology (4 application modes)
l DynamicsLCDTM - 128×64 pixel graphical interactive LC display with softkeys
l Start/stop logic for Diesel/Gas engines
l Engine pre-glow or purge control
l kWh meter, kvarh meter
l Operating hours/start/maintenance counters
l Configurable trip levels/delays/alarm classes
l Push-buttons (softkeys) for direct control
l PC and/or front panel configurable
l Multi-level password protection
l Multi-lingual capability (10 languages in 1 unit configurable: English, German, French, Italian, Spanish, Portuguese, Russian, Turkish, Chinese, Japanese)
l Event recorder (300 events, FIFO) with real time clock (battery backed; min. 6 years)
l Modem connectivity with DPC
l easYlite annunciator support via CAN bus
l Remote control via interface / digital signals
DIMENSIONS
Woodward ➟ USA ➟ 8440-1809
EASYGEN-1000 Genset Control
CONDITION NEW ➟ IN STONCK
|
|
|
|
