WESTINGHOUSE 5X00622G01 16-Channel RTD Input Module

16-Channel RTD (Resistance Temperature Detector) Input Module

Choose Amikon

l Amikon has a large number of industrial electronic components to choose from. New and discontinued. These range from 30 years to the latest technology. Investing in new technologies is not always necessary.

l We are happy to help you keep the old equipment in good condition. Are you or your customers experiencing serious electronic equipment failures in your business?

l Does the machine shut down and stop production? Therefore, a quick solution is in your best interest! Sometimes, it may be difficult to find the required components.

l Our large stock usually enables us to help you, so your production can be restarted immediately!

Sales manager：Miya zheng；Email:sales@amikon.cn；WhatsApp:86-18020776792；WeChat:86-18020776792；

Features

l 16 individually isolated thermocouple inputs

l Individual A/D converter per input channel

l Supports +/-20 mV, +/-50 mV, and +/-100 mV ranges

l Software tool supports standard selection options of B, E, J,K, N, R, S, and T type thermocouples

l Integral temperature sensor for cold junction compensation

l Supports grounded and ungrounded thermocouple

l Module hot-swap capability

l Open thermocouple detection capability

l Provides both normal and common-mode rejection

Overview

The Ovation™ 16 Channel Thermocouple Input module provides an interface between the Ovation Controller and up to 16 thermocouple signals. This module has an integral temperature sensor for cold junction compensation. This 16 Channel Thermocouple Input module requires a four-module I/O base (part number – 5X00497G01). The thermocouple wires terminate to the “+” and “-” connections on terminal rows B and C of the four-module I/O base respectively. For the ungrounded thermocouples, the shield should be terminated at the D strip. For the field grounded thermocouples, the shield and thermocouple are grounded at the sensor site.
