TRICONEX · TRICON CX · SAFETY I/O

3626X

Supervised Digital Output Module engineered for the Tricon CX safety control architecture, providing 32 commoned 24 VDC output points with TMR redundancy for safety-critical field actuation.

OUTPUT ARCHITECTURE

32-point · Commoned · TMR

FIELD VOLTAGE

24 VDC nominal

VOTING

TMR output architecture

POINTS

32 commoned outputs

DIAGNOSTICS

Output / load supervision

ENGINEERING PROFILE

Safety Output Layer

Designed for output functions where dependable switching, field-circuit supervision and fault-tolerant operation are important to the overall safety strategy.

Module family	Tricon CX
Signal type	Digital output
Nominal voltage	24 VDC
Output points	32

CONTROL PRIORITY

Availability · Diagnostics · Fault tolerance

PRODUCT DETAIL

Built Around a Fault-Tolerant Output Philosophy

The TRICONEX 3626X is a supervised digital output module for the Tricon CX platform. It provides 32 commoned 24 VDC output signals and uses a Triple Modular Redundant architecture to support high-availability safety control.

The output architecture combines redundant processing paths with voting and diagnostic functions so that output behavior can be monitored while the safety system continues its control role.

The module is intended for demanding industrial applications in which digital commands may be associated with shutdown, interlock, alarm or other safety-related field functions.

CORE ATTRIBUTES

Architecture	TMR
Output arrangement	Commoned
Output quantity	32
Nominal field supply	24 VDC
Output supervision	Yes

TECHNICAL DATA

3626X
At a Glance

Manufacturer / family	TRICONEX / Tricon CX
Model	3626X
Module type	Supervised Digital Output
Output signals	32 commoned
Nominal voltage	24 VDC
Recommended voltage range	20.4–28.8 VDC
Maximum usable voltage	28.8 VDC
Maximum over-voltage range	32 VDC
Maximum output current	1.70 ±10% A per point
Surge capability	5 A for 7 ms
Minimum required load	10 mA within 100 μs
Maximum output leakage	< 4.0 mA
Logic power	< 8 W
Module status indicators	PASS · FAULT · ACTIVE · LOAD

FAMILY POSITION

How 3626X Fits the Tricon CX I/O Architecture

3506X — Supervised Digital Input

The 3506X provides supervised digital input capability within the Tricon CX architecture. It is used where discrete field conditions must be brought into the safety control system.

3626X — Supervised Digital Output

The 3626X performs the complementary output role, transmitting voted digital commands toward field actuators and safety-related devices.

Within Tricon CX, the combination of supervised input and output modules creates a dedicated I/O layer for safety control. The 3626X should therefore be evaluated together with the required Tricon CX chassis, controller architecture and compatible field termination arrangement rather than as a generic 24 VDC output card.

FIELD ROLE

Where the Output Layer Matters

The 3626X is appropriate for safety-oriented digital output functions where the field command must remain under continuous diagnostic supervision. Typical roles include safety interlocks, shutdown commands, alarm actuation and other discrete field actions.

SHUTDOWN FUNCTIONS Suitable for discrete commands associated with protective shutdown and interlock logic.	FIELD ACTUATION Intended for field devices receiving 24 VDC digital safety outputs.
LONG-DURATION OUTPUTS Supervision is especially valuable when an output can remain in one state for extended periods.	DIAGNOSTIC MAINTENANCE Output, load and field-circuit conditions can be considered during fault investigation.

REPLACEMENT CONSIDERATION

When replacing a 3626X, confirm the Tricon CX platform, output point count, commoned arrangement, field voltage, compatible termination hardware and application load before selecting an alternative. A physically similar digital output module should not be treated as an automatic functional substitute.

PROCUREMENT SUPPORT

Need 3626X for an Existing System?

Send the complete part requirement before placing an order. This helps us check the requested configuration and prepare the most suitable quotation.

Please include:

Part Number · Quantity · Destination · Required Date · Machine/System

DIRECT CONTACT

Sales manager

Miya zheng

EMAIL · sales@amikon.cn WHATSAPP · 86-18020776792

Delivery	3–5 days
Warranty	12 months
Packaging	Brand New
Delivery way	E-packing / FedEx / EMS / TNT / DHL / UPS
Payment term	T/T

BUYER QUESTIONS

3626X Purchase & Replacement FAQ

01	Why is TRICONEX 3626X a better fit when the application requires supervised digital outputs? The 3626X combines 32 commoned 24 VDC outputs with supervised output functionality and TMR architecture. This makes it more appropriate for safety-oriented output circuits where the field load and output path require ongoing diagnostic attention.
02	How should TRICONEX 3626X be matched with the existing Tricon CX field termination arrangement? The 3626X should be matched to the compatible Tricon CX termination hardware and the actual field wiring arrangement. Point count, commoned output design and 24 VDC field requirements should all be checked before ordering a replacement.
03	What should be checked before replacing a TRICONEX 3626X with another digital output module? Check the Tricon CX platform, 32-point requirement, commoned configuration, 24 VDC field voltage, load characteristics, termination hardware and system configuration. Similar voltage alone is not sufficient to establish interchangeability.
04	When does TRICONEX 3626X make more sense than a conventional non-supervised output module? It becomes especially relevant when the output circuit itself, field load and wiring condition need to be monitored as part of the safety-control strategy. Conventional output modules may not provide the same supervised-output function.
05	What purchasing details should be confirmed before ordering TRICONEX 3626X for a critical replacement? Confirm the exact part number, required quantity, destination, required delivery date and the machine/system where the module will be installed. Providing the existing system context helps reduce configuration risk during replacement.
