TRICONEX 3614E TMR Supervised Digital Output Module

Calculate shipping

Quotation Request

TRICONEX SAFETY I/O

3614E

●	TMR supervised DO
●	Commoned output architecture

OUTPUT 8 POINTS commoned	VOLTAGE 20–36 VDC nominal 24 VDC
CURRENT 0.5 A / point 4 A surge / 10 ms	SWITCHING 150 W resistive maximum

AMIKON CONTACT

Miya zheng

✉ sales@amikon.cn ☎ 86-18020776792

◆

WE HAVE A WIDE RANGE OF BRANDS AND PRODUCTS FOR VARIOUS INDUSTRIES

Services for customers worldwide

Product Categories

Brands
- ABB
- BENTLY NEVADA
- HONEYWELL
- EMERSON
- ALLEN BRADLEY
- YOKOGAWA
- GENERAL ELECTRIC
- TRICONEX
- ICS TRIPLEX
- HIMA
- BACHMANN
- SIEMENS
- PROSOFT
- SCHNEIDER
- FOXBORO
- OTHERS

New Products

Product Details

TRICONEX
SAFETY I/O

3614E

TMR Supervised Digital Output Module

A supervised 24 VDC digital output module with eight commoned output signals for Tricon safety-system architectures.

CORE PROFILE

Architecture	TMR
Output type	Supervised DO
Nominal voltage	24 VDC

◈

The 3614E is designed for supervised digital output duties in Tricon systems, combining redundant control architecture with output supervision for safety-critical process applications.

◇

✉ EMAIL SALES@AMIKON.CN

☎ WHATSAPP 86-18020776792

TECHNICAL CORE

3614E

Supervised digital output
Commoned architecture
24 VDC class

Specification	3614E
Module type	TMR Supervised Digital Output Module
Nominal voltage	24 VDC
Voltage range	20 to 36 VDC
Output signals	8, commoned
Maximum carry current	0.5 A per point
Surge current	4 A for 10 ms
Maximum switching power	150 W, resistive load
Maximum output cycle rate	Less than 20 cycles/s

◉	For reactive loads, switching power must be derated. The documented maximum for DC reactive-load operation is 37.5 W, equal to 25% of the 150 W maximum. The module is not recommended for shunt-diode intrinsic-safety barriers; the 3615E is the designated alternative for that application.

WHY 3614E FITS A PROJECT

Supervised 24 VDC output duty

The 3614E is suited to Tricon applications where the output circuit must operate within a supervised digital-output architecture. Its eight commoned outputs and 24 VDC operating range make the module relevant when the existing system configuration specifically calls for this output class.

01 Output matching Confirm that the existing configuration requires 8 commoned supervised outputs.	02 Voltage matching Check that the field circuit is within the 20–36 VDC module range.
03 Load review Review carry current and switching power before replacing a module in an operating circuit.	04 Barrier application Do not treat 3614E as the preferred choice for shunt-diode intrinsic-safety barrier applications.

DIRECT SALES SUPPORT

Need a 3614E Replacement or Availability Check?

✉ EMAIL
sales@amikon.cn

◉ WHATSAPP / PHONE
86-18020776792

◆ SALES MANAGER
Miya zheng

DELIVERY
3–5 Days

WARRANTY
12 Months

PACKAGING
Brand New

DELIVERY WAY
E-packing / FedEx / EMS / TNT / DHL / UPS

PAYMENT
T/T

FOR A FAST QUOTATION, PLEASE PROVIDE

Part Number • Quantity • Destination • Required Date • Machine/System

PURCHASE & CONFIGURATION QUESTIONS

3614E FAQ

01 · Is 3614E the correct replacement when the existing output circuit is 24 VDC? 3614E is a 24 VDC nominal supervised digital output module with an operating range of 20–36 VDC and eight commoned outputs. Replacement should therefore be based on matching the existing system configuration and field-circuit requirements, not voltage alone.	02 · What should I verify before purchasing 3614E as a spare? Verify the exact module designation, the eight-point commoned output arrangement, the 24 VDC class, the field load requirements, and the applicable termination arrangement. These checks help prevent a nominal-voltage match from becoming a configuration mismatch.
03 · Can 3614E handle higher-current field loads? The documented maximum carry current is 0.5 A per point, with a 4 A surge rating for 10 ms. The specified maximum switching power for a resistive load is 150 W. Actual load characteristics should be checked before replacement.	04 · Is 3614E suitable for shunt-diode intrinsic-safety barriers? No. The Tricon planning guidance specifically states that 3614E is not recommended for shunt-diode intrinsic-safety barrier applications. The 3615E is identified for those applications, so the barrier arrangement should be checked before ordering.
05 · Why does the 3614E switching-power rating matter when replacing an installed module? The 3614E is rated at up to 150 W for resistive loads, while reactive DC loads require derating to 37.5 W. Checking the actual load type and switching duty is important when a spare module is being selected for an existing application.
