SIMATIC S7-1500 / FRONT CONNECTION
6ES7592-1AM00-0XB0
SIMATIC S7-1500 Front Connector · Screw-Type · 40-Pole
A 40-pole front connector for 35 mm wide SIMATIC S7-1500 modules. The screw-type connection system is supplied with four potential bridges and cable ties, creating a defined wiring interface between field conductors and the associated module.
|
PART PROFILE
S7-1500 Front Connector
Article number: 6ES7592-1AM00-0XB0
Connection: Screw terminals Number of poles: 40 Module width: 35 mm Included: 4 potential bridges + cable ties A dedicated front-connection choice for compatible 35 mm S7-1500 modules.
|
|
01 / TERMINAL SYSTEM
Screw Connection
The 40-pole front connector uses screw terminals. One conductor can be connected per terminal, or two conductors can be combined in a shared ferrule within the specified total cross-section.
|
02 / CONDUCTOR RANGE
0.25–1.5 mm²
Supported conductor cross-sections range from 0.25 mm² to 1.5 mm² for solid and flexible conductors, with the applicable limits also defined for conductors with end sleeves.
|
03 / INCLUDED ITEMS
4 + Cable Ties
The connector is supplied with four potential bridges and cable ties, supporting practical cabinet wiring and conductor organization.
|
|
6ES7592-1AM00-0XB0
40-pole screw-type front connector for 35 mm wide modules. Includes four potential bridges and cable ties.
Connection: Screw terminals
|
VS |
6ES7592-1BM00-0XB0
40-pole push-in front connector for 35 mm wide modules, also supplied with four potential bridges and cable ties.
Connection: Push-in
|
How to Choose
Choose according to the required terminal technology and the wiring practice of the installation. If an existing cabinet uses screw terminals, the exact 6ES7592-1AM00-0XB0 designation is the direct selection point.
Key decision: terminal technology
|
|
PURCHASE DESK
Need 6ES7592-1AM00-0XB0?
Send the part number, quantity, destination and required date. If the connector is replacing an installed unit, adding the S7-1500 module designation can help confirm the required 35 mm / 40-pole / screw configuration.
|
AMIKON / SALES MANAGER
Miya Zheng
Email: sales@amikon.cn
Phone / WhatsApp: +86 180 2077 6792 Delivery: 3–5 days Warranty: 12 months |
|
Does 6ES7592-1AM00-0XB0 fit every S7-1500 module?
No. This article is specified for 35 mm wide modules. The module width and front-interface requirement should be checked before ordering rather than assuming compatibility across the complete S7-1500 range.
|
When should 6ES7592-1AM00-0XB0 be chosen instead of 6ES7592-1BM00-0XB0?
Both are 40-pole front connectors for 35 mm wide modules, but 6ES7592-1AM00-0XB0 uses screw terminals while 6ES7592-1BM00-0XB0 uses push-in technology. The terminal technology of the existing or planned wiring determines the appropriate selection.
|
|
Can 6ES7592-1AM00-0XB0 accept two conductors on one terminal?
Yes, the specified arrangement permits one line per connection or a combination of two conductors up to a total of 1.5 mm² when using a shared ferrule. The applicable conductor cross-section limits should be respected.
|
Are the four potential bridges included with 6ES7592-1AM00-0XB0?
Yes. The listed supply includes four potential bridges as well as cable ties. This is useful when replacing a connector because the supplied accessories are part of the defined product package.
|
|
What should be included when requesting 6ES7592-1AM00-0XB0 for a cabinet replacement?
Provide the complete article number, quantity, destination, required date and the exact S7-1500 module designation. If the installed wiring uses screw terminals, stating that requirement helps distinguish this article from the push-in variant.
|
|
