SIEMENS · SIMATIC S7-200 SMART
6ES7288-2QR16-0AA0EM QR16 Digital Output Expansion Module
Siemens SIMATIC S7-200 SMART expansion module with 16 relay digital outputs. The EM QR16 is designed to extend digital output capability in S7-200 SMART control systems. REQUEST A QUOTE
|
PRODUCT IDENTIFICATION
EM QR16
Digital Outputs
16 DO
Relay Output · 2 A
|
|
OUTPUT TYPE
Relay
Digital output
|
OUTPUT COUNT
16 DO
16 relay outputs
|
RATED OUTPUT
2 A
Relay output rating
|
PROTECTION
IP20
Protection degree
|
| Product | SIMATIC S7-200 SMART EM QR16 |
| Article Number | 6ES7288-2QR16-0AA0 |
| Digital Outputs | 16 |
| Output Technology | Relay |
| Rated Output Current | 2 A |
| Protection Degree | IP20 |
| Dimensions | 45 × 100 × 81 mm |
| Approx. Weight | 220 g |
| Operating Temperature | 0°C to 55°C horizontal installation; 0°C to 45°C vertical installation |
| Storage / Transport Temperature | -40°C to +70°C |
| Relative Humidity | Up to 95% at 25°C, without condensation |
|
SYSTEM ROLE
Built for S7-200 SMART ExpansionThe EM QR16 expands the digital output capacity of a SIMATIC S7-200 SMART control system with 16 relay-based digital outputs. It is suited to control architectures where additional switching points are required for machine or process control. |
Why this module matters
When an output expansion module is unavailable or defective, connected actuators and machine sequences may not receive the required switching commands. For production equipment, restoring the correct output module can therefore be important to reducing troubleshooting and downtime.
|
|
01
Output Failure
A relay output does not switch as expected, preventing a connected machine function from operating correctly.
|
02
Expansion Requirement
An existing S7-200 SMART application requires additional digital output points for machine control.
|
03
Production Downtime
Loss of required digital outputs can interrupt machine sequences, making fast replacement important in time-critical maintenance.
|
|
DELIVERY
3–5 Days
|
WARRANTY
12 Months
|
PACKAGING
Brand New
|
|
