Key electrical, output, isolation and physical characteristics.
The module is designed for digital output expansion in the SIMATIC S7-200 SMART environment, where discrete output channels are required for machine and process control.
The SM DT08 is an expansion module for the S7-200 SMART system and adds eight digital transistor output channels to the automation configuration.
Its transistor outputs are intended for switching discrete 24 V DC loads. The outputs can also be used for controlling digital inputs and for specified parallel switching functions.
When an expected digital output is not switching correctly, maintenance personnel may check the output module, wiring, power supply and connected load as part of the troubleshooting process.
Supporting customers with fast communication and efficient industrial automation parts delivery.
AMIKON focuses on fast, reliable supply of industrial automation parts for customers who need to keep equipment and production systems running smoothly.
Our service is built around product identification, responsive communication, efficient order handling and dependable delivery. We aim to make the process of locating automation components straightforward, especially when an exact part number is required.
Five concise technical questions focused on the actual module characteristics.
The module provides eight digital outputs arranged in groups of two. The outputs are transistor type and current-sourcing.
The maximum specified switching capacity is 0.75 A with a resistive load and 5 W for a lamp load.
The rated DC value is 24 V, with a permitted supply range from 20.4 V to 28.8 V DC.
The digital outputs are electrically isolated between channels using optocouplers. The isolation is tested at 500 V AC for one minute.
The specified maximum cable length is 500 m for shielded cable and 150 m for unshielded cable.
No. The specified digital output stage does not provide short-circuit protection, so connected circuits should be checked carefully during installation and troubleshooting.
Selected models supplied across Siemens, ABB and other industrial automation ranges.
Send the key order information once. Our sales team can then review the requirement and respond with pricing and availability.
