SIEMENS 6ES7193-6BP60-0DA0 SIMATIC ET 200SP system 2-fold BaseUnit

Calculate shipping

Quotation Request

SIMATIC ET 200SP

6ES7193-6BP60-0DA0

BASE UNIT

Product Number

6ES7193-6BP60-0DA0

SIMATIC ET 200SP
2-fold BaseUnit

TYPE

BU Type A0

2-fold BaseUnit
2BU15-P16+A0+2DB

SIZE

30 × 117 × 35 mm

Width × Height × Depth

TERMINAL

Push-In

Conductor cross-section
0.14–2.5 mm²

Sales Manager

Miya zheng

sales@amikon.cn 86-18020776792

Product Categories

Brands
- ABB
- BENTLY NEVADA
- HONEYWELL
- EMERSON
- ALLEN BRADLEY
- YOKOGAWA
- GENERAL ELECTRIC
- TRICONEX
- ICS TRIPLEX
- HIMA
- BACHMANN
- SIEMENS
- PROSOFT
- SCHNEIDER
- FOXBORO
- OTHERS

New Products

Product Details

SIEMENS · ET 200SP

Overview Specs Application FAQ Contact

SIMATIC ET 200SP

6ES7193-6BP60-0DA0

2-fold BaseUnit · BU type A0 · 2BU15-P16+A0+2DB · Push-In terminals · without AUX terminals

30 × 117 × 35 mm Approx. 80 g Push-In

PART NUMBER

6ES7193-6BP60-0DA0

PRODUCT FORMAT

2-fold BaseUnit

BU type A0

CONNECTION

Push-In terminals

Supply voltage

24 V DC

P1 / P2 bus

10 A max.

Process terminals

2 A max.

Process terminals

16 / slot

TECHNICAL PROFILE

Connection & Electrical Structure

IDENTITY

Product family SIMATIC ET 200SP

Product type 2-fold BaseUnit

BU type A0

Terminal technology Push-In

AUX terminals Not included

ELECTRICAL & MECHANICAL DATA

Rated supply

24 V DC

P1 / P2 current

10 A max.

Process current

2 A max.

Process terminals

16 / slot

Conductor min.

0.14 mm² / AWG 26

Conductor max.

2.5 mm² / AWG 14

Width

30 mm

Height

117 mm

Depth

35 mm

Approx. weight

80 g

SYSTEM STRUCTURE

A compact two-position BaseUnit arrangement

POSITION

BU type A0

POSITION

BU type A0

→

TOTAL WIDTH

30 mm

2-fold BaseUnit

The configuration provides a new potential group. The AUX bus is not connected to AUX terminals on this version.

FIELD APPLICATION

Built for ET 200SP station architecture

This BaseUnit is part of the SIMATIC ET 200SP architecture and provides the mechanical and electrical interface associated with the connected I/O position.

WHEN A REPLACEMENT IS NEEDED

Typical searches occur when an ET 200SP station requires a matching BaseUnit because of terminal damage, mechanical wear, incorrect seating, or a maintenance replacement.

WHY THE PART MATTERS

A mismatched BaseUnit can affect mechanical assembly and electrical connection of the associated ET 200SP position, increasing troubleshooting time during maintenance.

MAINTENANCE SCENARIO

Three checkpoints before replacement

Match the part number

Confirm 6ES7193-6BP60-0DA0 before ordering.

Check the configuration

Verify the 2-fold A0 arrangement and Push-In connection.

Check replacement strategy

This part has reached the end of its product lifecycle, so replacement planning matters for maintenance.

Downtime consideration: a missing or unsuitable BaseUnit can delay restoration of an ET 200SP station position. Correct part-number matching helps reduce maintenance delays.

PRODUCT STATUS

Lifecycle consideration

Siemens lists 6ES7193-6BP60-0DA0 as a discontinued product. The product page indicates that the part is no longer available as a current product.

SUCCESSOR COMBINATION

1 × 6ES7193-6BP00-0DA0
+
1 × 6ES7193-6BP00-0BA0

20 Years of Industrial Automation Supply

For more than 20 years, AMIKON has focused on industrial automation parts supply, supporting customers with hard-to-find automation components and responsive service.

Urgent Industrial Automation Delivery

When production continuity matters, AMIKON supports urgent sourcing and delivery of industrial automation parts to help reduce maintenance delays.

AMIKON SUPPORT

Keeping automation maintenance moving

AMIKON has more than 20 years of experience in industrial automation parts supply. Our service focuses on hard-to-find automation components, responsive communication and practical order support.

Multilingual Support

Dedicated multilingual sales and customer service support.

Order Tracking

Customer-oriented order management and tracking support.

Urgent Shipping

Fast delivery arrangements for time-sensitive requirements.

No Hidden Fees

No rush handling fees or hidden processing charges.

ORDER SUPPORT

Need help finding the right part?

If you cannot locate the exact part number, our sales and customer service team can help review your requirement.

SALES MANAGER

Miya Zheng

sales@amikon.cn

PHONE / WHATSAPP

86-18020776792

DELIVERY

3–5 Days

WARRANTY

6–12 Months

PACKAGING

Brand New

PAYMENT

T/T

Delivery way: E-packing / FedEx / EMS / TNT / DHL / UPS

REQUEST DETAILS

Send the key details with your inquiry

Part Number

Quantity

Destination

Required Date

Machine / System

CONTACT

Miya Zheng

sales@amikon.cn 86-18020776792

POLICY

Refund &
Replacement

Contact within 7 days

Please contact us within 7 days if you have any question after receiving the item.

Original condition

Returned items should remain in their original condition with a specific reason for the return.

Return shipping

The buyer is responsible for shipping costs incurred for the return.

PURCHASING & REPLACEMENT QUESTIONS

6ES7193-6BP60-0DA0 — Practical FAQ

Can the 6ES7193-6BP60-0DA0 be replaced by a single 6ES7193-6BP00-0DA0?

No. The Siemens replacement arrangement is not a one-for-one single-unit substitution. Siemens specifies one 6ES7193-6BP00-0DA0 together with one 6ES7193-6BP00-0BA0 as the successor combination.

What should be checked when an existing ET 200SP BaseUnit is being replaced?

Match the complete article number first, then verify the BaseUnit arrangement, BU type, terminal technology and AUX-terminal configuration. For this part, the defining combination is 2-fold BU type A0 with Push-In terminals and no AUX terminals.

Is the 30 mm width related to the two-position construction?

Yes. Siemens specifies this product as a 2-fold BaseUnit with a width of 30 mm. Its height is 117 mm and its depth is 35 mm.

Does this version provide AUX terminals for an ET 200SP installation?

No. The 6ES7193-6BP60-0DA0 is specified as a version without AUX terminals. This is an important point to verify when matching an existing installation.

What is the maximum conductor range for the Push-In connection?

The specified conductor range is 0.14 mm² / AWG 26 minimum to 2.5 mm² / AWG 14 maximum.

What should be considered if this exact part is no longer available?

The lifecycle status needs to be considered before purchasing. Siemens identifies this part as discontinued and specifies a successor arrangement consisting of one 6ES7193-6BP00-0DA0 and one 6ES7193-6BP00-0BA0. The installation configuration should be checked before changing the hardware.
