Product Overview
The Siemens 6ES7193-6BP00-0DA0 is a SIMATIC ET 200SP BaseUnit, designated BU15-P16+A0+2D and classified as BU type A0. It is designed for compatible ET 200SP I/O modules and provides the electrical and mechanical interface required for distributed I/O construction. The unit uses Push-In terminals, has no AUX terminals and supports the formation of a new potential group. Its 15 mm width is suited to the compact ET 200SP station architecture, while the 16 process terminals provide the connection interface for compatible peripheral modules. For replacement planning, the important selection point is not only the physical width but also the BaseUnit type, terminal arrangement, potential-group behavior and compatibility with the installed I/O module. |
PART NUMBER
6ES7193-6BP00-0DA0
Family
SIMATIC ET 200SP BaseUnits BaseUnit
BU15-P16+A0+2D |
| Part Number | 6ES7193-6BP00-0DA0 | Quantity | Required quantity |
| Destination | Shipping destination | Required Date | Target delivery date |
| Machine / System | Installed equipment or control system | ||
|
DIRECT SALES CONTACT
Miya zheng
Sales Manager · Industrial Automation Parts
|
EMAIL sales@amikon.cn |
PHONE / WHATSAPP 86-18020776792 |
| Lead Time 3–5 days |
Warranty 12 months |
Condition Brand New |
Delivery E-packing / FedEx / EMS / TNT / DHL / UPS |
| Payment Term T/T |
Order Support Configuration and replacement coordination |
||
|
Functional Characteristics
01 / Compact Architecture
15 mm width supports the compact ET 200SP station concept. 02 / Push-In Connection
Push-In terminal technology provides a direct wiring interface for compatible applications. 03 / New Load Group
This A0 BaseUnit is designed to establish a new potential group. 04 / No AUX Terminals
The configuration is provided without AUX terminals, matching the specific BU15-P16+A0+2D arrangement. |
Technical Snapshot
|
|
When to Select
Select this BaseUnit when the ET 200SP configuration requires a BU type A0 unit with 15 mm width, Push-In terminals, 16 process terminals and a new potential group.
|
Replacement Check
Before replacement, compare the BaseUnit type, width, terminal technology, potential-group arrangement and the installed I/O module family. A physically similar BaseUnit is not automatically an equivalent replacement.
|
Typical Service Scenario
The part is relevant when an ET 200SP station requires replacement of a damaged or worn BaseUnit while retaining the intended module arrangement and electrical grouping.
|
The ET 200SP BaseUnit family includes multiple configurations with different terminal arrangements and BaseUnit types. For the A0 group, Siemens lists variants such as BU15-P16+A0+2D, BU15-P16+A0+2B, and versions with A10-related configurations. The correct selection depends on the connected I/O module and required potential-group arrangement.
| Model | Configuration | Terminal | Selection Focus |
| 6ES7193-6BP00-0DA0 | BU15-P16+A0+2D | Push-In | New load group |
| 6ES7193-6BP00-0BA0 | BU15-P16+A0+2B | Push-In | Different A0 arrangement |
| 6ES7193-6BP00-0DA1 | BU15-P16+A0+2D/T | Push-In | A1 / temperature-related module applications |
