Product Details

SIMATIC ET 200SP

Product Technical Application FAQ Contact

SIMATIC ET 200SP

6ES7134-6GD00-0BA1

AI 4xI 2-/4-wire ST

SIMATIC ET 200SP analog input module with four current inputs for 2-wire and 4-wire transducers.

4 × Current Input 2-/4-Wire 16-bit

PRODUCT STATUS

Spare Part

Successor

6ES7134-6GD01-0BA1

System

SIMATIC ET 200SP

Module Type

Analog Input

KEY VALUES

Technical Core

6ES7134-6GD00-0BA1

INPUTS

Current inputs

SIGNAL

0–20 mA

4–20 mA / ±20 mA

RESOLUTION

16-bit

Including sign

SUPPLY

24 V DC

Rated L+

≡

MODULE DETAILS

Specification Overview

Product designation AI 4xI 2-/4-wire ST

Article number 6ES7134-6GD00-0BA1

BaseUnit A0 / A1

Rated load voltage DC 24 V

Input quantity 4

Input type Current

Transducer connection 2-wire / 4-wire

Module diagnostics Supported

I&M data Supported

Firmware update Supported

Address space 8 bytes

Dimensions W × H × D 15 × 73 × 58 mm

CURRENT MEASUREMENT

Supported Ranges

Current 0–20 mA

Current 4–20 mA

Current ±20 mA

DIAGNOSTIC FUNCTIONS

Monitoring Capability

Wire break Overflow Underflow L+ supply Short circuit

SYSTEM ROLE

Designed Around ET 200SP Analog Acquisition

Distributed signal acquisition

The module is used in a SIMATIC ET 200SP station when four analog current channels are required for 2-wire and/or 4-wire transducers.

SIGNAL FLEXIBILITY

0–20 mA, 4–20 mA and ±20 mA measurement ranges are available.

Service and replacement situations

A replacement search can arise when an installed module reports an internal fault, wire break, under-range or over-range condition, short-circuit condition, or loss of the required load voltage.

● Abnormal analog acquisition

● Diagnostic condition on the affected module

● Loss of required process measurement

AMIKON

20 Years of Industrial Automation Supply

For more than 20 years, AMIKON has focused on industrial automation parts supply and support for customers working with automation equipment and control systems.

FAST RESPONSE

Urgent Automation Parts Supply

When an automation component is needed for maintenance or replacement, AMIKON provides responsive communication and delivery coordination to help reduce operational delays.

FREQUENT QUESTIONS

6ES7134-6GD00-0BA1 FAQ

What type of input does the 6ES7134-6GD00-0BA1 provide?

It provides four analog current inputs and supports 2-wire and 4-wire transducers.

Which current ranges can be configured?

The supported current ranges are 0–20 mA, 4–20 mA and ±20 mA.

What resolution does this analog input module use?

The 0–20 mA and 4–20 mA ranges use 15-bit resolution, while ±20 mA uses 16-bit resolution including the sign.

Which BaseUnits are suitable for the 6ES7134-6GD00-0BA1?

The module is suitable for BaseUnit types A0 and A1.

What diagnostic conditions can lead to a replacement search?

Diagnostic conditions include internal module error, under-range, over-range, wire break, short circuit and missing or insufficient L+ supply.

What should be checked before ordering this part?

Confirm the complete article number, quantity, destination, required date and the machine or system in which the module is installed.
