Summary
XKB-A34207 is a Harmony XK heavy-duty two-axis joystick that delivers 1-to-3-notch, 12°-20°-28° detented motion and IP54-sealed IP20 mechanics for reliable, ergonomic control of cranes and conveyors in –20 °C…+70 °C industrial environments.
Details
|
Movement: 2 axes, 4 directions, 1–3 notches selectable (12°/20°/28° per direction) |
|
Contacts: 1 NO + 1 NC per direction, 10 A 500 V AC, 6 A 250 V DC |
|
Mechanical life: 1 million cycles, 20 gn shock 11 ms, 6 gn vibration 1…70 Hz |
|
Protection: IP54 front, IP20 rear, IK08 impact, TC protective treatment |
|
Temperature: –20…+70 °C operating, –40…+70 °C storage |
|
Mounting: Ø30 mm panel hole, screw-clamp terminals 2×2.5 mm² |
|
Dimensions/mass: 152 × 165 × 241 mm, 0.88 kg; CE, UL, ABS marine approved |
