Schneider MA-0186-100 Coaxial Cable Splitter

Choose Amikon

We're faster.

No matter where parts are in the world, we will strive to find all kinds of spare parts for your equipment quickly and efficiently.

l International Delivery on the Day

l Quick Response Support

l Intercontinental Cooperation Network

⇒Sales manager：Miya zheng；Email:sales@amikon.cn；WhatsApp:86-18020776792；WeChat:86-18020776792

Descripution

The Schneider Electric MA-0186-100 serves as a coaxial cable splitter, functioning as a repeater in signal transmission setups. This module is adept at duplicating a signal from one cable, facilitating applications that require the use of two cables, configured in a ring topology. The device measures 1.18 inches in height, 3.35 inches in width, and extends 7.05 inches in length, making it a compact solution for various installation challenges. Weighing in at 3.46 ounces (98 grams), it is lightweight yet durable.

Designed with sustainability in mind, the MA-0186-100 is mercury-free and compliant with the EU RoHS Directive, ensuring it meets environmental standards. In terms of operational resilience, it can tolerate humidity levels between 5% and 95% without condensation, ensuring reliable performance under varied environmental conditions. The module has been tested for vibration resistance up to 1 g and can withstand shock forces of 15 g. Its IP68 rating guarantees excellent protection against dust and water, making it suitable for challenging conditions where reliability is crucial.

Specifications

The Modicon MA-0186-100 Splitter must used as a signal combiner in a 984 Hot Standby cable system; each programmable controller (with an S911 or R911 Hot Standby module in it) has the ability to transmit onto the network using the splitter.

MA-0186-100 splitters have a minimum return loss of 18 dB on each port. Any unused port must be terminated. The splitter is installed between two PLCs in the main trunk cable and has three connectors (ports) on it. Each port is attenuated 6 dB from the other ports. All ports are split equally.

Please contact us for more related Information！！！

Sales manager：Miya zheng；Email:sales@amikon.cn；WhatsApp:86-18020776792；WeChat:86-18020776792

FAQ

Q1: What distinguishes the Schneider MA-0186-100 in Modicon Quantum coaxial network architectures, and why is it considered essential for signal repetition?
A: The Schneider MA-0186-100 functions as a coaxial cable repeater/splitter, enabling a single coaxial communication line to be expanded into a dual-cable configuration while preserving reliable signal transmission across the network.

Q2: How does the Schneider MA-0186-100 enhance communication reliability in distributed Modicon Quantum automation systems?
A: The Schneider MA-0186-100 regenerates and repeats communication signals to reduce transmission degradation, helping maintain stable and consistent data exchange between connected automation devices over extended cable distances.

Q3: Why should engineers integrate the Schneider MA-0186-100 when expanding a Modicon Quantum coaxial communication network?
A: The Schneider MA-0186-100 provides an efficient method of extending existing coaxial networks without major infrastructure changes, supporting improved network flexibility, simplified expansion, and dependable communication performance.

Q4: Which industrial applications can benefit most from deploying the Schneider MA-0186-100 repeater module?
A: The Schneider MA-0186-100 is well suited for manufacturing plants, process automation facilities, utility systems, and other industrial environments where Modicon Quantum controllers require reliable coaxial network expansion and uninterrupted communication.

Q5: What operational advantages does the Schneider MA-0186-100 provide for long-term industrial automation maintenance?
A: The Schneider MA-0186-100 features a compact industrial design, simple installation, dependable signal regeneration, and compatibility with Modicon Quantum communication networks, helping reduce maintenance efforts while improving overall system availability.
